Metro ESP32-S2 - WiFi module with ESP32-S2 chip
search
  • Metro ESP32-S2 - WiFi module with ESP32-S2 chip
  • Metro ESP32-S2 - WiFi module with ESP32-S2 chip
ID: 587290
5906623430598
zł125.87
Tax included

zł102.33 tax excl.

Module with WiFi Espressif ESP32-S2. It integrates two regulators, SPI Flash memory, LiPo charging circuit and RGB diode. It is equipped with a STEMMA QT connector. Adafruit 4775

24h
Available
Available quantity: 3
Kamami is the official distributor of Adafruit modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

Module with WiFi Espressif ESP32-S2. It has 4 MB of Flash memory, 2 MB of external PSRAM memory, integrated WiFi 802.11 b/g/n transceiver and a connector for connecting a LiPo battery. There is an RGB diode on the board. In addition, the user has at his disposal two 3.3 V and 5 V LDO regulators, which are responsible for powering the ESP system and can be used to power external modules. The pin layout is compatible with the Arduino Uno R3. Metro ESP32-S2 can be easily integrated with sensors due to the available STEMMA QT connector (compatible with Qwiic).

The module offers great possibilities in the field of IoT systems and can be used both to control LEDs and to transfer data to a specific platform. It can also be programmed using the Arduino IDE, ESP-IDF or CircuitPython. Full documentation is available on the product page.

Features

  • 240MHz 32-bit single-core processor
  • 4 MB SPI Flash Memory
  • 2 MB of additional PSRAM
  • 2.4 GHz Wi-Fi - 802.11b/g/n
  • 3D antenna
  • 5V and 3.3V LDO regulators
  • Optimized power system ensuring low energy consumption
  • LiPo battery management
  • Power, charging and user LEDs
  • Connectors compatible with Arduino UNO R3
  • UART and JTAG debugging connector
  • On/Off switch
  • Power supply: USB type C or DC connector
  • RGB NeoPixel LED
  • Ambient light sensor ALS-PT19 (IO14)
  • Qwiic/STEMMA connector
  • Dimensions: 53.2 x 72 x 14.8 mm
587290
