ESP32-S3 development board with 4.3″ display 800×480 - Waveshare 30493
ID: 1197700
5902186305113
zł125.52
Tax included
zł102.05 tax excl.
ESP32-S3-LCD-4.3 is an advanced evaluation board for graphical and IoT applications, offering a high level of integration with an IPS display, wireless connectivity, and a rich set of interfaces. The non-touch version allows focus on implementing visual interfaces in control systems, data visualization, and consumer devices, while ensuring flexibility and ease of integration.
Description
Evaluation board with the ESP32-S3N8R8 microcontroller, featuring a dual-core Xtensa® LX7 processor clocked up to 240 MHz and integrated 2.4 GHz Wi-Fi and Bluetooth 5 (LE) connectivity. The board includes a 4.3-inch color IPS display with a resolution of 800×480 pixels and a 160° viewing angle, supporting 65 thousand colors. The standard version (non-touch) is ideal for implementing graphical applications using the LVGL environment. The board includes 8 MB of Flash memory and 8 MB of PSRAM, along with a wide range of peripheral interfaces: CAN, RS485, I2C, TF card slot, and both UART and full-speed USB.
Features
- Microcontroller: ESP32-S3N8R8, 2× Xtensa® LX7, 240 MHz
- Memory: 512 KB SRAM, 384 KB ROM, 8 MB PSRAM, 8 MB Flash
- Connectivity: Wi-Fi 802.11 b/g/n, Bluetooth 5 (LE), ceramic antenna
- Display: 4.3" IPS LCD, 800×480 px, 65K colors
- Interfaces: CAN (TJA1051T/3/1J), RS485 (SP3485), I2C, TF card slot, sensor header
- USB ports: USB Type-C (full-speed) and USB to UART
- Power supply: via USB Type-C or lithium battery connector (PH2.0)
- Extras: BOOT and RESET buttons, status indicators (power, charging, charge complete), 3.3 V LDO (800 mA), CS8501 charger
- Compatible with LVGL and supports rapid HMI application development
Included in the set
- ESP32-S3-LCD-4.3 board
- 2× HY2.0 2P to 2PIN male cable (10 cm)
- 1× HY2.0 3P to 3PIN male cable (10 cm)
- 1× HY2.0 4P to 4PIN male cable (10 cm)
- Standoff set
1197700
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
