ID: 1198715
5902186322592
zł493.53
Tax included

zł401.24 tax excl.

Solar-powered communication node integrating LoRa, GPS and XIAO nRF52840 Plus microcontroller, ready to work thanks to pre-installed Meshtastic software. The device is equipped with a 5W solar panel and four 18650 batteries, which ensures reliable operation even in limited sunlight and makes it ideal for field work. Thanks to its long range (up to 8-9 km), support for many navigation systems and the possibility of expansion via the Grove interface, the P1-Pro will be useful in environmental monitoring, IoT, exploration and emergency communication. Seeed Studio 114993633

4 weeks
Awaiting delivery
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

SenseCAP Solar Node P1-Pro is a self-sustaining communication node powered by solar energy, designed to operate in areas without traditional network access. It integrates a XIAO nRF52840 Plus main controller, Wio-SX1262 LoRa module, and XIAO L76K GPS module, enabling precise positioning and long-range communication with minimal power consumption. Thanks to the built-in Meshtastic software, the device is ready to use straight out of the box.


Equipped with a 5W solar panel and four 18650 batteries, each with a capacity of 3350mAh, the node ensures continuous operation even in low sunlight conditions. It is ideal for outdoor environments where reliable power is essential. The GPS module provides accurate real-time location data, supporting GPS, GLONASS, and Galileo systems. With the included Grove interface, connecting various sensors is simple, making this device an extremely versatile monitoring tool. The communication range between two devices can reach up to 8–9 km in open terrain. The device can serve as a field node, repeater, or expansion point for the Meshtastic network, effectively extending its range. It is perfect for environmental monitoring, IoT applications, field exploration, and emergency communication.

Features

  • Main controller: XIAO nRF52840 Plus (ARM Cortex-M4, 64 MHz, 256KB RAM, 1MB Flash + 2MB additional memory)
  • LoRa module: Wio-SX1262 (Semtech SX1262, transmit power up to 22dBm, 868–915 MHz)
  • GPS module: XIAO L76K (supports GPS/GLONASS/Galileo/BeiDou)
  • Antennas:
    • LoRa: rod antenna, 2 dBi, 868–915 MHz
    • GNSS: GPS L1 (1575.42 MHz), GLONASS L1 (1602 MHz), BeiDou B1 (1561.098 MHz)
  • Bluetooth: 5.0
  • Solar panel: 5W
  • Interfaces: 1× Grove (IIC/GPIO/UART), USB-C for debugging
  • Buttons: power on/off, reset, programmable
  • LED indicators: charging (×2), solar panel status (×1), mesh signal (×1), programmable (×1)
  • Power input: USB-C 5V 1A or solar panel 5V 1A
  • Battery: 4× 18650 rechargeable batteries (3350 mAh each)
  • Operating environment: -40°C to +60°C
  • Certifications: CE, FCC
  • Dimensions: 191.2 × 201.2 × 42.1 mm

Kit contains

  • SenseCAP Solar Node P1-Pro (with GPS and batteries)
  • Mounting kit (ball connector, adapter, clamp, mounting ring)
  • Rod antenna 2 dBi 868–915 MHz ×1
  • RF cable RP-SMA male to RF-SMA female (300 mm)
  • Black USB-C cable
  • User manual
