ID: 1202929
zł169.00
Tax included

zł137.40 tax excl.

A low-power LoRa communication node with pre-installed Meshtastic software, designed for field operation and ultra-low-power IoT applications. It is based on the Nordic nRF52840 microcontroller and the SX1262 LoRa module, providing long-range mesh communication and Bluetooth connectivity. The integrated L76K GPS module enables precise location tracking, and the detachable 2.13" ePaper display allows for constant information presentation with minimal power consumption. Seeed Studio 114993654

4 weeks
Awaiting delivery
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Wio Tracker L1 E-ink is a low-power Meshtastic communication node designed for applications such as asset tracking, digital signage, and field-deployed IoT projects. The device uses LoRa technology (862–930 MHz), enabling long-range, low-power wireless communication. At its core is the Nordic nRF52840 microcontroller, delivering high performance with minimal energy consumption. The module comes with preinstalled Meshtastic firmware, making it ready to use right out of the box. An integrated L76K GPS module supporting GPS, BeiDou, GLONASS, and QZSS ensures accurate real-time positioning.


The E-ink version supports a detachable 2.13" ePaper display, optimized for ultra-low power consumption and continuous information display. Wio Tracker L1 E-ink offers three power supply options: USB-C, a solar panel, or a 3.7 V Li-ion battery, making it ideal for mobile and outdoor installations. The device is fully compatible with the Grove ecosystem and also provides PTH headers and an SWD interface for hardware expansion and advanced debugging. By combining LoRa, Bluetooth 5.0, GPS, and e-ink, Wio Tracker L1 E-ink is well suited for mesh networks, smart city projects, localization systems, and applications requiring long battery life. It is a robust and scalable platform for professionals and IoT enthusiasts who need a reliable solution for operation in demanding environments.

Features

  • Processor: Nordic nRF52840, ARM® Cortex®-M4 with FPU, up to 64 MHz
  • Memory: 1 MB Flash, 256 kB RAM
  • Wireless connectivity: LoRa (862–930 MHz), Bluetooth 5.0
  • LoRa module: Wio-SX1262
  • GPS: L76K (GPS, BeiDou, GLONASS, QZSS)
  • Supported displays: 2.13" E-ink, 1.3" OLED
  • ePaper display: 2.13", 122 × 250 px, 4 grayscale levels
  • Refresh time: partial 0.42 s, full 3 s
  • Display power consumption: 10.5 mW (typ.), standby 0.003 mW
  • Interfaces: Grove (UART/I2C/GPIO), PTH (UART/I2C/GPIO/Analog), SWD
  • Power supply: USB-C 5 V / 1 A, solar panel 5 V / 1 A, 3.7 V Li-ion battery / 1 A
  • Certifications: FCC, CE, RoHS

Kit contents

  • Wio Tracker L1 board
  • 2.13" ePaper display
  • RF cable 60 mm (RP-SMA Female to IPEX)
  • LoRa antenna
  • GPS antenna
  • 24-pin FPC connector, 0.5 mm pitch
  • 24-pin FFC cable
