Crowtail-Mini PIR Motion Sensor 2.0 – miniature digital PIR motion sensor, DSP, 2 m, 5 V
ID: 1201707
5902186332133
zł26.27
Tax included
zł21.36 tax excl.
Crowtail-Mini PIR Motion Sensor 2.0 is a miniature digital PIR sensor with a built-in DSP and RFI filter, intended for motion detection in compact systems. It is used in alarms, lighting control and robotics.
Description
Crowtail-Mini PIR Motion Sensor 2.0 is a compact and energy-efficient digital motion sensor using PIR (Passive Infrared) technology. Based on the S16-L221D chip with digital signal processing (DSP), it provides precise presence detection within a range of up to 2 meters. The built-in filter increases resistance to radio-frequency interference (RFI), improving reliability in environments with high noise levels. Thanks to its small size and the Crowtail interface, the module can be easily integrated into alarm systems, smart lighting, presence-monitoring devices and robotics projects.
Properties
- Crowtail connector – digital
- PIR technology with digital signal processing (DSP)
- Built-in filter – high resistance to radio-frequency interference
- Chip: S16-L221D
- Sensitivity: 120–530 µV
- Best detection distance: >2 m
- Maximum detection range: 2 m (at 25°C)
- Low energy consumption
- Dimensions: 20 × 20 mm
1201707
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
