ART-Pi - development board with STM32H750 microcontroller
ID: 1178452
zł459.34
Tax included
zł373.45 tax excl.
Development board with STM32H750 microcontroller. Equipped with a WiFi/Bluetooth module, it offers numerous interfaces and a set of external memory extending the possibilities of the system. DFRobot DFR0942
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Development board with STM32H750 microcontroller based on ARM Cortex-M7 core. It is equipped with a double-precision FPU unit and a clock operating at a frequency of 480 MHz. The microcontroller has a built-in 128 KB of Flash memory and 1 MB of RAM memory, but it also has an external NOR Flash W25Q64 memory with a capacity of 8 MB and W25Q128 with a capacity of 16 MB, which significantly extends the possibilities of the system. The board has a microSD card slot, an LCD display connector with an RGB888 interface, a USB OTG interface and an AP6212 module that adds WiFi and Bluetooth communication. External circuits can be connected to two sets of 40-pin connectors located on the periphery of the board. The process of uploading the code is easy and intuitive thanks to the built-in ST-Link V2-1 programmer. The set will work in demanding projects, where the user needs a large number of different peripheral systems.
Features
- STM32H750XBH6 microcontroller: Cortex-M7 core, frequency up to 480 MHz, 16 KB I / D cache and 1 MB RAM
- 2 x NOR Flash (W25Q128, W25Q64)
- AP6212 (WiFi + Bluetooth)
- USB-OTG (type C interface)
- Two buttons (user and reset)
- LCD (RGB 888)
- SD RAM (32M)
- SD card
- Raspberry Pi expansion ports
- ART expansion ports
- Built-in ST-Link V2-1
1178452
