The RP2040 microcontroller board features two ARM Cortex-M0+ cores running at 133 MHz, 264 kB of RAM. The board also features 2 MB of QSPI flash memory and an FPC connector. It comes with a USB adapter. Waveshare RP2040-Tiny-Kit

4 weeks
Awaiting delivery
Kamami is the official distributor of Waveshare displays, accessories and modules.



Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The board features the RP2040 microcontroller designed by the Raspberry Pi Foundation. The chip has two ARM Cortex M0+ cores running at up to 133 MHz and 264 kB of RAM. The microcontroller is not equipped with Flash memory, but there is a 2MB external memory on the board connected via the QSPI interface.


1. FPC 4. RP2040
2. RT9193-33 5. WS2812
3. NOR-Flash 2 MB

In addition to the RP2040 chip and Flash memory, the user has a 3.3 V voltage stabiliser, an RGB diode and GPIO outputs where peripherals such as 12-bit ADC, PWM inputs, I2C, SPI and UART interfaces are brought out. The module is programmed via an 8-pin FPC connector (an FPC-USB adapter is required). The use of such a connector reduces the size of the board and eliminates the protruding USB connector, making it easier to install in the target device.


An adapter with FPC and USB connector and Boot and Reset buttons is included for convenient programming of the module.


The platform supports the popular MicroPython and C/C++ programming languages. Programmes can be uploaded to the memory using a USB interface. A guide with examples of use is available on the product page.

Features

  • RP2040 microcontroller designed by Raspberry Pi
  • Two ARM Cortex-M0+ cores clocked at up to 133 MHz
  • 264 kB of on-board SRAM
  • LDO 3.3 V 500 mA stabiliser
  • Built-in FPC 8-pin connector for programming and power supply
  • USB typu C adapter
  • 20 x multi-function GPIO pins: ADC, UART, SPI, I2C, PWM
  • WS2812 RGB LED
  • 2 MB external flash memory
  • Supported programming languages: MicroPython and C/C++
  • Dimensions: 23.5 x 18 mm

Kit contains

  • RP2040-Tiny
  • RP2040-Tiny-Adapter
  • 8PIN FPC cable ~15cm
1185247

Data sheet

Microcontroller
RP2040
Flash memory
2 MB
Number of I/O
20
Ethernet
none
WiFi/BT module
No
Bluetooth module
No
MicroSD slot
No
Length
23,5 mm
Width
18 mm
USB connector type
Brak
