2-Axis Pan-Tilt Camera Module with OV5647 camera and 2-DoF platform for Raspberry Pi 4B/5 - Waveshare 26519
ID: 1189005
5906623466092
zł514.93
Tax included
zł418.64 tax excl.
Camera module with a two-degree-of-freedom (2 DoF) platform. It uses the OV5647 sensor with a resolution of 5 MP and provides a 360° camera rotation angle thanks to the built-in servo. It is dedicated to the Raspberry Pi 4B and Raspberry Pi 5 minicomputers. 2-Axis Pan-Tilt Camera Module (EU)
Description
Camera module with a platform with two degrees of freedom (2 DoF) and expandability. It uses serial bus-controlled servos with a high torque of 30 kg*cm, adapted to various applications. The rotation range in the horizontal axis (PAN) is up to ±180° (360° in total), and in the vertical axis (TILT) from -45° to 90°. The module is based on a universal robot controller and provides open sources for creating web applications that enable taking photos, video recording, face detection, motion detection, etc.
The kit comes with an OV5647 camera with 5MP resolution and 160-degree viewing angle, allowing you to capture a wider area to meet different visual demands. Precise servomechanisms equipped with a magnetic encoder with a 12-bit resolution were used to move the camera. This allows for feedback such as rotation angle and load, enabling closed-loop control.
The kit includes a Picatinny rail and 1/4 screw, as well as open source code for models and drawings. This makes it easier for users to integrate the PAN-TILT camera module into other projects.
The set allows you to connect and control using mobile phones, tablets and computers. Thanks to open access to the sources of the web application, the user can independently expand the application to adapt the interface and add new functions.
Features
- Degrees of freedom (DoF): 2
- Rotation angle: 360° (horizontal), 135° (vertical)
- The base is driven by a servo controlled by a TTL serial bus
- Servo rotation speed: 40 rpm
- Angle sensor: 12-bit 360° magnetic encoder
- Servo torque: 30kg*cm at 12V
- Feedback: servo status, joint angle, rotation speed, joint load, servo voltage, servo current, servo temperature and servo operation mode
- Main controller: ESP32-D0WD-V3
- Communication interface: USB, UART
- OV5647 5MP camera with 160° viewing angle
- LED lighting
- Web application for control
- Included with a rail for mounting an additional camera/camera
- Compatible with Raspberry Pi 4B, Raspberry Pi 5
- Weight: 441g
Kit contains
- Bearing holder
- 2 x Servo mounting plates
- 3 x Pan-Tilt metal handles
- 2 x Chassis mounting plates
- LED with PH2.0 male plug
- RPi camera (G) (with cable)
- ST3215 servo (with cable and screws)
- 2 x 3-pin 300mm servo connection cable
- FFC cable 15-pin 600 mm
- Ball plain bearing
- 2.4G antenna
- DC5521 to XH2.54 male cable 15 cm
- PH2.0 cable with double 4-pin plug, 20 cm
- IPEX 1 to SMA cable 17 cm
- 0.91 inch OLED display
- Robot controller
- 5 x Transparent suction cup 5.3 cm
- 12V 5A power supply
- Screwdriver
- Jetson Nano Adapter (A)
- Cable 2*5pin 9cm
- USB Type A Male to Type C Male Cable 1 m
- Mini cross wrench sleeve
- Picatinny rail (with key)
- Key
- Black FFC 15-pin 400 mm tape
- Pi5 camera cable 500 mm
- 8 x Silicone non-slip feet
- Screw set
1189005
Data sheet
- Resolution
- 5MPx
- Interface
- nie dotyczy
- Sensor
- OV5647
- IR filter
- Yes
- Lens assembly
- none
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
