Single Board Computer with Raspberry Pi CM4 – 4×1.5 GHz, eMMC, mPCIe, RS-232, Gigabit Ethernet (ED-CM4SEN-1208-C)
ID: 1195075
5902186308213
zł750.30
Tax included
zł610.00 tax excl.
ED-CM4SEN-1208-C is a single board computer with a Raspberry Pi CM4 and a quad-core ARM Cortex-A72 1.5 GHz processor, equipped with eMMC, mPCIe, PCIe, Gigabit Ethernet, and five RS-232 ports. The design with a heatsink and an operating range of -25°C to 60°C allows it to be used in demanding industrial and network projects.
Description
The ED-CM4SEN-1208-C single board computer is based on the Raspberry Pi Compute Module 4 (CM4102008) with a quad-core ARM Cortex-A72 1.5 GHz processor. It is equipped with a heatsink for passive cooling as well as mPCIe and PCIe expansion slots. It features built-in eMMC storage for the system and data. Communication interfaces include Gigabit Ethernet, two USB 2.0 Type-A ports, a micro USB Type-B port, and five RS-232 ports (with RS-422 and RS-485 support). The device is designed to operate in temperatures from -25°C to 60°C, in a desktop enclosure measuring 103 × 73 mm.
Properties
- Processor: ARM Cortex-A72, 4 cores, 1.5 GHz
- Module: Raspberry Pi CM4 (CM4102008)
- Cooling: heatsink
- Storage: eMMC
- Expansion slots: mPCIe, PCIe
- Ethernet: 10/100/1000 Mbps
- USB: 2 × USB 2.0 Type-A, 1 × micro USB Type-B
- RS-232/422/485: 5 ports
- Dimensions: 103 × 73 mm
- Form factor: desktop enclosure
- Operating temperature: -25°C to 60°C
1195075
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
