Industrial controller based on Raspberry Pi Compute Module 5, ideal for edge computing, IoT and industrial automation. Equipped with Broadcom BCM2712 processor, 8 GB RAM and 32 GB eMMC, it has Ethernet, RS232/485 interfaces and digital and analog I/O. Robust metal housing with DIN rail mounting and optional 4G/LTE and NVMe SSD modules provide durability and flexibility for industrial applications. Cytron IRIV-PICL5-W832

24h
Available
Available quantity: 1
Kamami is the official distributor of Cytron modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

IRIV PiControl CM5 is a modern industrial controller designed to meet the challenges of the Fourth Industrial Revolution, leveraging the power of the Raspberry Pi Compute Module 5. This compact and versatile device is an ideal solution for industrial applications requiring high performance and reliability.

Thanks to the Broadcom BCM2712 processor, 8 GB of RAM, and 32 GB of eMMC storage, the IRIV PiControl CM5 offers flexibility and scalability in industrial use cases. The device excels in areas such as edge computing, enabling local data processing and real-time decision-making. With support for the IoT, it can act as a gateway to transmit data to the cloud for analysis and process optimization. In industrial automation, the IRIV PiControl can serve as the main controller, managing machines, sensors, and other devices in real-time. Its solid metal housing with passive cooling and DIN rail mounting makes it suitable for harsh environments.


The IRIV PiControl CM5 features a comprehensive set of interfaces including digital and analog inputs/outputs, Ethernet, RS232, and RS485, making it compatible with a wide range of equipment. With WiFi, Bluetooth, and optional 4G/LTE modules, the device offers multiple communication options. Additional features such as a real-time clock, cryptographic chip, and OLED display enhance functionality and ease of use. The device supports multiple operating environments including Linux and Windows, ensuring seamless integration with existing systems. The IRIV PiControl CM5 is also suitable for robotics applications, enabling motion control, sensor integration, and support for autonomous systems on production lines.


Expandable memory via M.2 NVMe SSD slot and optional mini PCIe slot provides future-proofing for further development. IRIV PiControl allows precise monitoring and data logging, enabling rapid fault detection and predictive maintenance planning. Power supply range of 10–30V with overvoltage protection ensures safe and stable operation. The IRIV PiControl CM5 is a comprehensive solution that supports process optimization, improved efficiency, and production quality in modern industrial facilities.

Features

  • Processor: Broadcom BCM2712, Quad-Core Cortex-A76 64-bit SoC @ 2.4GHz
  • RAM: 8GB
  • Storage: 32GB eMMC, expandable via M.2 NVMe SSD
  • GPU: 800 MHz VideoCore VII, supports OpenGL ES 3.1
  • Interfaces:
    • 1x HDMI 2.0 (4K@60Hz)
    • 2x USB 2.0
    • 1x USB-C (boot and debug)
    • 1x RJ45 Gigabit Ethernet
    • 1x RJ45 Ethernet (10/100M)
    • 4x isolated digital inputs (up to 50V)
    • 4x isolated digital outputs (up to 50V)
    • 4x isolated analog inputs (0-5V / 0-10V / 0-20mA)
    • 1x isolated RS232
    • 1x isolated RS485
  • Connectivity: WiFi IEEE 802.11 b/g/n/ac 2.4/5.0GHz, Bluetooth 5.0, BLE
  • Additional features:
    • PCF85063A Real-Time Clock
    • ATECC608B Crypto Authentication
    • 0.96” OLED display
    • Programmable buttons and LEDs
    • Active buzzer
  • Power supply: DC 10 to 30V with overvoltage protection
  • Enclosure: metal, fanless, DIN rail mounting
  • Dimensions: 141.2 x 83.5 x 39.5 mm

Kit contains

  • IRIV PiControl
  • Raspberry Pi CM5 with 8 GB RAM and 32 GB eMMC
  • Dual-band antenna for CM5
  • 85 mm x 3 mm flat screwdriver
  • 85 mm x 3 mm Phillips screwdriver
  • 4 x silicone feet
  • 8 x 3 mm black standoffs
