zł47.07 tax excl.
The KAmodRPi5 PCIe-M.2 adapter allows you to easily connect an NVME SSD to a Raspberry Pi 5 computer, ensuring universal installation, communication via the PCI Express interface, stable power supply voltage and LED indicators, while maintaining compatibility with HAT modules and official cooling
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The KAmodRPi5 PCIe-M.2 adapter is a solution that allows you to seamlessly connect an NVME SSD with an M.2 M-KEY connector to a Raspberry Pi 5 computer. Thanks to its universal design, the adapter allows you to install drives of the popular size 2280, as well as smaller variants : 2260, 2242 and 2230. It is designed to occupy the standard space intended for HAT expansion modules, but at the same time does not limit the possibility of using a heat sink with a fan dedicated to Raspberry Pi 5. The adapter is easy to install on Raspberry Pi 5 and can be connected with it via a 40-pin GPIO connector and an FFC 16/0.5 tape (it is also possible to connect only using the FFC tape). The adapter draws power directly from the Raspberry Pi 5 computer, therefore it is recommended to use a power supply for Raspberry Pi 5 with an appropriate power of at least 5.1 V and 3 A. LED indicators indicating correct power supply and disk activity allow the user to monitor the operating status.
Features
- Designed for Raspberry Pi 5
- Connection via FFC tape and GPIO 40 pin connector (connection only possible via tape)
- Possibility to add additional HAT modules
- Supported disk formats: 2230, 2242, 2260 or 2280
- M.2 Key M connector (NGFF)
- NVMe protocol support
- PCI Express Gen2 x1 interface (optional also Gen3 x1)
- LED indicators indicating power status and disk activity
- Power supply from Raspberry Pi (recommended power supply of at least 5.1 V 3 A)
- Possibility of mounting on Raspberry Pi Active Cooler
- It does not block access to other connectors
- Dimensions: 56 x 89 mm
Attention!
Not every M.2 NVME drive is compatible with the Raspberry Pi 5 computer. Tested and working drive models include:Goodram PX500 (256 GB, 2280)
Samsung 980 (500GB, 2280)
Samsung PM991a (256GB, 2242)
Patriot P310 (240GB, 2280)
Included
- KAmodRPi5 PCIe-M.2 adapter
- FPC tape - 1 pc.
- Mounting kit:
- M2 screw - 2 pcs.
- Distance - 1 pc.
- M.2 drive mounting screw
