PCIe TO 2-CH SATA HAT+ - PCIe SATA adapter for Raspberry Pi 5
ID: 1199754
5902186331617
zł78.30
Tax included
zł63.66 tax excl.
This adapter allows you to connect two SATA 3.0 drives to the Raspberry Pi 5 via a 16-pin PCIe interface. The device operates as a HAT+ and is automatically detected by the Raspberry Pi OS without the need for driver installation. It supports 2.5" and 3.5" drives, offers speeds of up to 6 Gb/s, and is fully compliant with AHCI 1.2 and NCQ. Ideal for building NAS servers, data storage systems, and IoT projects. Waveshare PCIe TO 2-CH SATA HAT+
Description
PCIe TO 2-CH SATA HAT+ is an expansion card that allows you to connect two SATA hard drives to a Raspberry Pi 5 without the need to install drivers. The device is fully compliant with the HAT+ standard, ensuring automatic hardware detection and configuration by the Raspberry Pi OS system. The adapter connects to the Raspberry Pi 5 via a 16-pin PCIe interface, offering two SATA 3.0 (6 Gb/s) ports compatible with PCIe Gen2 and SATA Gen3 standards.
The module supports both 2.5” and 3.5” drives, with power supply options for 5V and 12V, making it ideal for server, NAS, data storage, and IoT applications. Thanks to the built-in EEPROM chip, the adapter stores HAT+ identification data and product information, allowing for automatic configuration loading. The board also features two LED indicators that signal operational status, making it easy to monitor drive activity. The device supports Native Command Queuing (NCQ) and the AHCI 1.2 specification, ensuring high data transfer performance and low latency. It supports power-saving modes L0s / L1 and SATA partial/sleep power management features. The adapter does not require additional power if the connected drives do not use a 12V supply. When used with the latest version of Raspberry Pi OS, the module operates in plug-and-play mode without driver installation. The entire design follows the new HAT+ standard, ensuring perfect fit and full compatibility with Raspberry Pi 5 boards.
Features
- Standard: HAT+ (compatible with Raspberry Pi 5)
- Connector: 16-pin PCIe Gen2
- Interface: PCIe to 2× SATA 3.0 (6 Gb/s)
- Compatibility: SATA Gen3 / PCIe Gen2
- Supported drives: 2.5" and 3.5" (SATA 5V/12V)
- Communication: AHCI SPEC 1.2, NCQ (Full-Speed Command Queue)
- Power-saving modes: L0s / L1, SATA partial/sleep
- EEPROM: stores HAT ID and product information
- LED indicators: 2 pcs, indicating SATA channel activity
- Power supply: via 40-pin GPIO of Raspberry Pi or external (DC 3.5 × 1.3 mm)
- Single channel speed: up to 6 Gb/s (limited to 5 Gb/s by Pi 5)
- System support: Raspberry Pi OS (latest version – no drivers required)
- Plug & Play function – no configuration needed
- Dimensions: 85 × 56.5 mm
Kit contains
- PCIe TO 2-CH SATA HAT+
- 2 x SATA Adapter Cable
- 16PIN PCIe cable
- Screws pack
1199754
Data sheet
- Compatible with
- Raspberry Pi 5
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
