PCIe-to-M.2 NVMe SSD adapter (2x2230/2242 PCIe Gen2 x1) bootable for Raspberry Pi 5 - Waveshare 27480
ID: 1196640
5902186307179
zł74.10
Tax included
zł60.24 tax excl.
The PCIe TO 2-CH M.2 HAT+ expands the functionality of the Raspberry Pi 5 by enabling the installation of two NVMe SSDs, offering significantly improved read/write performance and the option to boot from disk. With its compact design, support for 2230/2242 form factors, and built-in power monitoring, the adapter is well-suited for server solutions, NAS projects, multimedia systems, and advanced industrial applications.
Description
The PCIe TO 2-CH M.2 HAT+ adapter expands the Raspberry Pi 5 by adding support for two NVMe solid-state drives in M.2 2230 or 2242 form factors, providing fast data access and the ability to boot the operating system from an SSD. The adapter connects to the Raspberry Pi 5 main board via a 16PIN PCIe FFC connector, compliant with the PCIe x1 Gen2 standard.
The board features two M.2 B-key sockets, status LEDs for each drive, an EEPROM chip, and a power monitoring circuit to ensure stable operation even under heavy data loads. The HAT+ design guarantees compact fitting and full hardware integration with the Raspberry Pi 5.
Features
- Compatible with Raspberry Pi 5, PCIe 16PIN interface (PCIe x1 Gen2)
- Supports two M.2 NVMe SSDs in 2230 and 2242 form factors
- Allows Raspberry Pi 5 to boot from an NVMe SSD
- NVMe protocol only, no SATA support
- Two SSD activity status LEDs
- SSD power monitoring circuit and EEPROM for improved system stability
- Compact HAT+ design, easy to mount without modifying the Raspberry Pi 5
- Dimensions: 65x56,5mm
Included
- PCIe TO M.2 HAT+ x1
- 2×20 pin header x1
- 16PIN FFC cable (40 mm) x1
- Mounting screw set x1
1196640
Data sheet
- Compatible with
- Raspberry Pi 5
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
