Expansion Shield X300 for Raspberry Pi B+/2B/3B
ID: 559623
5902186311800
zł269.83
zł176.19
Save zł93.64
Tax included
zł143.24 tax excl.
Lowest price 30 days:
zł269.83
Expansion Shield X300 with RTC real time clock; audio input and output; USB hub; Bluletooth, WIFI; SATA interface. Compatible with Raspberry Pi Model B+, Pi 2 Model B and Pi 3 Model B
Description
Expansion Shield X300 is a one of the most cost-effective shield which could apply to Raspberry Pi Model B+, Raspberry Pi 2 Model B and newest Raspberry Pi 3 Model B. It integrates a lot of very useful functions such as RTC real time clock; audio input and output; USB hub; Bluletooth, WIFI; SATA interface. With this shield, you can build Raspberry Pi projects more easily and save both time and cost.
Features
- Input Voltage: 6V to 18Vdc converted to 5V, 4A via step-down DC/DC converter to power the Raspberry Pi
- SATA: Allows you to connect SATA devices to your Raspberry Pi
- Audio:
- 3.5mm MIC in jack
- 3.5mm stereo audio jack
- SPDIF output
- Audio IO connector (Microphone input and stereo audio amplifier 3.3Wx2)
- Wireless:
- WiFi (IEEE 802.11b/g/n) with external antenna
- IR sensor (38KHz)
- Bluetooth serial communication
- USB Storage: Self-powered USB hub with 3 ports
- Real-time clock (RTC): Based on DS3231SN with included CR2032 battery
- Power output socket
- Camera flex slot so camera can still be used with the expansion board attached
- DIP switch to remove connection from RPi’s pin header
- Directly connected on top of the Raspberry Pi using the board GPIO header pins
- No wiring nor soldering is required
- Duplicated the 40-pin header of the R-Pi in order to support existing expansion boards
- Suitable for Raspberry Pi Model B+ and Raspberry Pi 2 Model B Dimensions: 85 x 56mm (Same size as Raspberry Pi)
Attention: When you power Raspberry Pi with the shield power resource, please don't power it again via the Micro-USB port, it will damage the board!
Package includes:
- 1 x X300 expansion board
- 1 x USB adapter
- 1 x 2.4GHz WIFI antenna
- 4 x nylon spacers (M3 x 20mm)
- 8 x nylon screws (M3 x 6mm)
559623
Data sheet
- Compatible with
- Raspberry Pi 3/2/B+
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
