- New
Siglent SDS812X - 2-channel 100Mhz digital oscilloscope
ID: 1195545
zł2,148.99
Tax included
zł1,747.15 tax excl.
This digital oscilloscope offers 12-bit vertical resolution and a sampling rate of up to 2 GSa/s, ensuring exceptional precision and measurement performance. Equipped with a 7-inch, capacitive touchscreen with a resolution of 1024x600 and an advanced trigger system with serial bus analysis, it enables intuitive operation and comprehensive signal diagnostics. With remote control via LAN and USB and support for VXI-11, SCPI, and USBTMC protocols, the SDS812X is ideal for automated test systems.
Description
The SDS812X from SIGLENT is a modern digital oscilloscope designed for users who demand exceptional accuracy, functionality, and intuitive operation. Equipped with 12-bit analog-to-digital converters, it delivers four times higher vertical resolution than standard 8-bit systems, enabling highly precise measurements of analog signals. The device offers a sampling rate of up to 2 GSa/s and waveform capture rate of up to 500,000 waveforms per second in sequence mode, significantly enhancing real-time diagnostic efficiency. Thanks to SPO (Super Phosphor Oscilloscope) technology, the oscilloscope features 256-level intensity grading and color temperature display mode, making it easier to identify rare anomalies.
The modern 7" capacitive touchscreen with high resolution (1024×600) supports multi-touch gestures, streamlining menu navigation and waveform analysis. The device includes an advanced digital triggering system supporting various modes—from basic to serial bus analysis (UART, I2C, SPI, etc.). Available features include power analysis, mask tests, history waveform recording, and Bode plots. The oscilloscope can be remotely controlled via LAN or USB interfaces using VXI-11, SCPI, Socket, and USBTMC protocols, making it an excellent tool for test automation and integration with measurement systems.
Features
- Bandwidth: 100 MHz
- Number of channels: 2 analog channels + 16 digital
- Sampling rate (max):
- Single-channel mode: 2 GSa/s
- Dual-channel mode: 1 GSa/s
- Four-channel mode: 500 MSa/s
- Waveform capture rate (max):
- Normal mode: 120,000 wfm/s
- Sequence mode: 500,000 wfm/s
- Maximum record length:
- Single-channel mode: 50 Mpts/ch
- Dual-channel mode: 25 Mpts/ch
- Four-channel mode: 10 Mpts/ch
- Display: 7" TFT-LCD, 1024×600 resolution, touchscreen with gesture support
- SPO technology: 256-level intensity grading, color temperature mode
- Advanced triggering system: edge, pulse width, serial bus, and more
- Special features: power analysis, mask testing, history recording, Bode plot
- Interfaces: USB Host/Device (USBTMC), LAN (VXI-11, Telnet, Socket), Pass/Fail, Trigger Out
- Dimensions: 312 × 151 × 132.6 mm
- Weight: 2.6 kg
Kit contains
- SIGLENT SDS812X oscilloscope
- USB cable
- 2 × PP510 passive probes
- Power cord
- Quick start guide
- Factory calibration certificate
1195545
Data sheet
- Type of oscilloscope
- Digital
- Bandwidth
- 100 MHz
- Sampling rate
- 2 Gsps
- Memory depth
- 50 Mpts
- Number of channels
- 2
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
