2.9″ e-Paper (G) display with Bluetooth 296×128 - Waveshare 29535
ID: 1197563
5902186307483
zł59.91
Tax included
zł48.71 tax excl.
The ESL-ePaper-2.9G display is an efficient solution for remote and energy-saving information display in applications such as shelf labels, asset tagging, or identification systems in retail and industry. The four-color screen and integration with the Waveshare cloud platform make the device ideal for environments requiring frequent content updates without physical intervention.
Description
The 2.9-inch e-paper display ESL-ePaper-2.9G from Waveshare's Electronic Shelf Label (ESL) series is a compact device designed for wireless content display using Bluetooth Low Energy (BLE 5.0) communication. With its four-color screen (red, yellow, black, white), low power consumption, and the ability to update images via the cloud using the ESL-Gateway-AP, the device is well-suited for digital labeling systems, logistics, and retail environments.
Specifications
- Diagonal: 2.9"
- Display technology: E Ink (electrophoretic)
- Resolution: 296 × 128 px
- Active area: 66.9 × 29.06 mm
- DPI: 112
- Colors: red / yellow / black / white
- Communication: Bluetooth Low Energy 5.0 (2.4 – 2.485 GHz)
- Operating temperature: 0 – 40°C
- Housing: ABS plastic
- Power supply: built-in 1200 mAh battery (replaceable)
- Operating time: up to 5 years (typical use)
- Viewing angle: 178°
- External dimensions: 92 × 41.5 × 7.5 mm
1197563
Data sheet
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 2,9
- Resolution
- 296 x 128 px
- Interface
- Bluetooth
- Touch
- No
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
