e-Paper display set 2.13″/2.66″/2.9″/3.5″ with ESL-Gateway-AP - Waveshare 30033
ID: 1197654
5902186321892
zł1,764.47
Tax included
zł1,434.53 tax excl.
The complete ESL set from Waveshare enables wireless management of electronic labels in various sizes, making it an ideal solution for stores, warehouses, and industrial signage systems. With BLE support and an integrated cloud platform, the system allows centralized content management with high energy efficiency and long operating time without the need for frequent battery replacement.
Description
The ESL (Electronic Shelf Label) set from Waveshare includes four e-paper displays with diagonals of 2.13", 2.66", 2.9", and 3.5", utilizing E Ink technology to display content in red, yellow, black, and white. Each label is enclosed in a durable ABS housing and powered by a replaceable 1200 mAh lithium battery, providing up to 5 years of operation. The set is compatible with the included ESL-Gateway-AP base station, enabling wireless content updates via the Waveshare.cloud platform using BLE (Bluetooth Low Energy) 5.0/5.1.
Specifications
- Common parameters
- Display type: E Ink, no backlight
- Display colors: red / yellow / black / white
- Power supply: 1200 mAh replaceable battery
- Operating time: up to 5 years
- Operating temperature: 0–40°C
- Housing: ABS plastic
- Communication interface: BLE 5.0 / 5.1
- Managed via ESL-Gateway-AP with access to cloud platform
Individual label specifications
2.13" ESL-ePaper-2.13G
- Resolution: 250 × 122 px
- Active area: 48.55 × 23.7 mm
- DPI: 130
- Dimensions: 71 × 34.7 × 11.6 mm
2.66" ESL-ePaper-2.66G
- Resolution: 296 × 152 px
- Active area: 60.09 × 30.7 mm
- DPI: 125
- Dimensions: 85 × 41 × 9.7 mm
2.9" ESL-ePaper-2.9G
- Resolution: 296 × 128 px
- Active area: 66.9 × 29.06 mm
- DPI: 112
- Dimensions: 92 × 41.5 × 7.5 mm
3.5" ESL-ePaper-3.5G
- Resolution: 384 × 184 px
- Active area: 79.68 × 38.18 mm
- DPI: 122
- Dimensions: 101.5 × 50 × 11.8 mm
ESL-Gateway-AP base station
- Communication: BLE + WiFi (2.4 / 5 GHz)
- Coverage: up to 30 m (indoors)
- Bandwidth: up to 1167 Mbps
- Power supply: 48 V PoE
- Dimensions: 180 × 180 × 33 mm
- Operating temperature: -10 to +60°C
Included in the set
- ESL-ePaper-2.13G ×1
- ESL-ePaper-2.66G ×1
- ESL-ePaper-2.9G ×1
- ESL-ePaper-3.5G ×1
- ESL-Gateway-AP ×1
- Mounting base ×1
- Network cable (~1 m) ×1
- Mounting screw set ×1
- PoE power supply ×1
1197654
Data sheet
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- Nie dotyczy
- Resolution
- Inna
- Interface
- Bluetooth
- Touch
- No
