Development board with 7-inch touch display, Wi-Fi 6 and OV5647 camera – Waveshare 32511
ID: 1201079
5902186330245
zł268.00
Tax included
zł217.89 tax excl.
ESP32-P4-WIFI6-Touch-LCD-7B-C development board with IPS touch display and OV5647 camera designed for applications based on image recognition, voice interaction and remote control. High performance, Wi-Fi 6 support and a wide range of interfaces make it a comprehensive tool for modern AIoT and HMI projects.
Description
Advanced development board integrated with a 7-inch IPS touch display with a resolution of 1024 × 600 and an OV5647 camera, based on the ESP32-P4-Core module and ESP32-C6-MINI, providing Wi-Fi 6 and Bluetooth 5 LE support. The 5 MP OV5647 camera connected via the MIPI CSI interface enables real-time image acquisition, supported by the built-in ISP processor and hardware JPEG/H264 codec. The module is ideal for AIoT applications, HMI systems, image recognition, voice processing and industrial communication. A rich set of interfaces (RS485, CAN, UART, I2C, USB OTG) and expansion options make it a flexible platform for advanced embedded system development. Advanced security features such as Secure Boot and Flash encryption ensure protection of data and code.
Properties
- Microcontroller: ESP32-P4 (dual-core + single-core, RISC-V, 240 MHz)
- Wireless communication: Wi-Fi 6 (2.4 GHz), Bluetooth 5 LE (ESP32-C6-MINI, SDIO)
- Memory: 32 MB Flash, 32 MB PSRAM
- Camera: OV5647, 5 MP, MIPI CSI (2-lane), ISP support, JPEG, H264
- Display: 7" IPS, 1024 × 600, RGB565/RGB666/RGB888, brightness 350 cd/m², contrast 600:1, 160° viewing angle
- Touch panel: capacitive, GT911, 5-point touch support
- Audio interfaces: ES8311 codec, ES7210 echo cancellation chip, two MEMS microphones, speaker connector
- Communication interfaces: CAN, RS485, UART, I2C (PH2.0 connectors)
- Multimedia interfaces: MIPI CSI (camera), MIPI DSI (LCD), microSD slot (SDIO 3.0)
- Security: Secure Boot, Flash Encryption, TRNG, access separation, key manager
- Power and ports: USB Type-C (debug, power), USB OTG (Type-A), power switch
- RTC: CR1220 connector, real-time clock backup
- Additional connectors: GPIO 2×12 (17 I/O lines), SH1.0 4-pin (RTC), PH2.0 for communication
- Board dimensions: 164 × 97 mm
- Display dimensions: 164.28 × 99.17 mm
Included
- ESP32-P4-WIFI6-Touch-LCD-7B-C board x1
- OV5647 camera with FPC cable x1
- Dual-plug USB Type-A cable x1
- USB Type-A to Type-C cable (approx. 1 m) x1
- Speaker x1
- SH1.0 4-pin cable (approx. 150 mm) x1
- PH2.0 12-pin cables (approx. 200 mm) x2
- PH2.0 4-pin cables (approx. 200 mm) x4
1201079
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
