- New
ESP32-H2-Zero development board with ESP32-H2FH4S microcontroller, BLE/Zigbee/Thread – Waveshare 32261
ID: 1201207
zł16.63
Tax included
zł13.52 tax excl.
ESP32-H2-Zero is a miniature development board with the ESP32-H2FH4S microcontroller, offering support for BLE 5, Zigbee and Thread, intended for IoT applications and wireless communication in compact embedded systems. Thanks to extensive peripherals and support for ESP-IDF and Arduino, it is a universal tool for rapid prototyping and application deployment.
Description
ESP32-H2-Zero is a compact development board based on the ESP32-H2FH4S microcontroller with a 32-bit RISC-V core clocked up to 96 MHz. Integrated 4 MB Flash memory and a wide range of peripherals (SPI, UART, I2C, I2S, PWM, ADC) enable the implementation of advanced functions in IoT and automation applications.
The board supports BLE 5 and IEEE 802.15.4 (Zigbee 3.0, Thread) wireless communication, allowing it to be used in smart home systems, industrial automation and consumer electronics. The built-in USB Type-C connector allows easy programming and debugging. The module can be soldered directly to baseboards thanks to castellated edges. Libraries and examples are available for the ESP-IDF and Arduino IDE environments.
Properties
- ESP32-H2FH4S microcontroller with 32-bit RISC-V core, up to 96 MHz
- Built-in 4 MB Flash memory
- Support for wireless communication: BLE 5, Zigbee 3.0, Thread (IEEE 802.15.4)
- USB Type-C interface for programming and debugging
- Integrated 2.4 GHz ceramic antenna
- Built-in BOOT and RESET buttons
- WS2812 RGB LED for status indication
- Built-in 3.3 V LDO regulator (800 mA max)
- Peripherals: SPI, UART, I2C, I2S, PWM, ADC
- Castellated edges for soldering to baseboards
- Support for ESP-IDF and Arduino IDE
- Dimensions: 23.5 × 18 mm
1201207
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
