Terasic DE1-SoC-MTL2 (K0159) - ACADEMIC (EDU)
ID: 235121
zł3,613.70
Tax included
zł2,937.97 tax excl.
DE1-SoC + 5 points multitouch display MTL2
ATTENTION! This product is for academic recipients (students and academic teachers) only!
After the ordering, please send us by e-mail the data listed below:
- the name and last name
- position (student, teacher)
- e-mail (with the University domain)
- University name
- Facultie / Section
- University address
- University phone no.
- End user application
Description
The DE1-SoC-MTL2 Development Kit is a comprehensive design environment with everything embedded developers need to create processing-based systems. The DE1-SoC-MTL2 delivers an integrated platform including hardware, design tools, and reference designs for developing embedded software and hardware platforms in a wide range of applications. The fully integrated kit allows developers to rapidly customize their processor and IP to best suit their specific application. The DE1-SoC-MTL2 features a DE1-SoC development board targeting Altera Cyclone® V SX SoC FPGA, as well as a capacitive LCD multimedia color touch panel which natively supports five points multi-touch and gestures.
The all-in-one embedded solution offered on the DE1-SoC-MTL2, in combination of a LCD touch panel and digital image module, provide s embedded developers the ideal platform for multimedia applications with unparallel processing performance. Developers can benefit from the use of FPGA-based embedded processing system such as mitigat ing design risk and obsolescence, design reuse, lowering bill of material (BOM) costs by integrating powerful graphics engines within the FPGA.
For SoC reference design in Linux for touch-screen display, please refer to the DE1-SoC-MTL2 Control Panel .
Features
- DE1-SoC Development Board
- Cyclone V SX SoC—5CSEMA5F31C6N
- Dual-core ARM Cortex-A9 (HPS)
- 85K programmable logic elements
- 4,450 Kbits embedded memory
- 6 fractional PLLs
- 2 hard memory controllers
- Configuration Sources
- Quad serial configuration device – EPCS128 for the FPGA
- On-board USB Blaster II (normal type B USB connector)
- Memory Device
- 64MB (32Mx16) SDRAM for the FPGA
- 1GB (2x256MBx16) DDR3 SDRAM for the HPS
- microSD card socket for the HPS
- Peripherals
- Two port USB 2.0 Host (ULPI interface with USB type A connector)
- UART to USB (USB Mini B connector)
- 10/100/1000 Ethernet
- PS/2 mouse/keyboard
- IR emitter/receiver
- I2C multiplexer
- Connectors
- Two 40-pin expansion headers
- One 10-pin ADC input header
- One LTC connector (one Serial Peripheral Interface (SPI) master ,one I2C bus, and one GPIO interface)
- Display
- 24-bit VGA DAC
- Audio
- 24-bit CODEC, Line-in, line-out, and microphone-in jacks
- Video Input
- TV decoder (NTSC/PAL/SECAM) and Video-in connector
- ADC
- Fast throughput rate: 1 MSPS
- Channel number: 8
- Resolution: 12-bit
- Analog input range : 0 ~ 2.5 V or 0 ~ 5V by selecting the RANGE bit in the control register
- Switches, Buttons and LEDs
- 5 user keys (4 for the FPGA and 1 for the HPS)
- 10 user switches for the FPGA
- 11 user LEDs (10 for the FPGA and 1 for the HPS)
- 2 HPS reset buttons (HPS_RESET_n and HPS_WARM_RST_n)
- Six 7-segment displays
- Sensors
- G-Sensor on HPS
- Power
- 12V DC input
- Cyclone V SX SoC—5CSEMA5F31C6N
- Capacitive Multi-touch Screen
- LCD Display
- 7-inch TFT LCD with pixel resolution of 800*480
- 16 million colors (8-bit RGB)
- LED backlight
- Capacitive Muti-Touch
- Five points multi-touch
- I2C interface
- Gesture supporting
- Gesture Table
- One Point
- Two Point
- One Point
- LCD Display
Layout
- Size:354*130*20 mm
Kit Contents
- DE1-SoC-MTL2 Kit
- DE1-SoC-MTL2 Quick Start Guide
- Type A to B USB Cable
- Type A to Mini-B USB Cable
- MicroSD Adapter
- 8GB microSD Card (Pre-programmed & Installed)
- Card Reader
- Power DC Adapter (12V)
Resources
235121
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
