Grove Solid State Relay V2 - module with SSR relay
ID: 583206
zł87.59
Tax included
zł71.21 tax excl.
Module with relay SSR G3MC202P with a load up to 2 A. The board is equipped with a Grove connector and is controlled via digital input. Seeed Studio 103020137
Description
Module with SSR relay G3MC202P with a load of up to 2 A. It enables switching devices with high power using, for example, a microcontroller. The relays are controlled with the voltage of 5 V. Compared to electromechanical relays, SSRs are based on semiconductor devices (transistors and thyristors) and offer faster switching speeds. However, they can only control alternating voltage. The board is equipped with a Grove connector, so it can be used with the Base Shield V2 and Arduino extension. The module is controlled via digital input and is supplied with the voltage of 5 V. The set includes an acrylic housing that protects the module against damage. Full documentation of the module with examples of use is available on the product page.
Features
- Operating voltage: 4 to 6V
- Rated input voltage 5V
- Load voltage range 75 to 264 VAC 50/60 Hz
- Rated load voltage 100 to 240 VAC 50/60 Hz
- Load current 0.1 to 2 A
- Leakage current 1.5 mA max. (at 200 VAC)
- Insulation resistance 1000 MΩ (at 500 VDC)
- Working time: ½ cycle of load power source +1 ms
- Release time: ½ load feed cycle + 1 ms
- Interface: digital input
- Output interface: 2-pin terminal
- Supply voltage: 3.3 V or 5 V
- Dimensions: 40 x 40 x 25 mm
- Weight: 131 g
Kit contains
- Grove Solid State Relay V2 module
- Grove cable
- Acrylic case
583206
Data sheet
- Output current
- 2A
- Number of channels
- 1
- Executive element
- SSR
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
