New products
New products
zł22.17 tax excl.
LiPo 3.7 V battery charger module with a microUSB socket. DFRobot DFR0667
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
LiPo 3.7 V battery charger module with microUSB socket. It is based on the TP4056X charging system, which guarantees fast and safe charging with one of three current values (depending on the battery capacity). The module has an LED indicator that blinks after connecting the power supply in the absence of a battery, it lights up during charging and goes out when the process is completed. There are 3 charging modes: trickle charge, constant current charge and constant voltage charge, which guarantee safety and save charging time.
Features
- Charging indicator (LED)
- Safe and fast charging
- Input voltage: 5V
- Charging current: 50 mA (100 to 400 mAh), 200 mA (400 to 1000 mAh), 500 mA (above 1000 mAh)
- Limited charging voltage: 4.2V ± 1%
- Working temperature: -40 ℃ to 85 ℃
- Dimensions: 16.5 x 25 mm
