Gravity: MAX30102 Heart Rate and Oximeter Sensor - a module with a heart rate monitor
ID: 1178592
5902186310162
zł111.32
Tax included
zł90.50 tax excl.
Module with a pulse sensor and the level of SpO2 (oxygen saturation level). It is based on the MAX30102 chip and communicates via the I2C or UART interface (Gravity connector). DFRobot SEN0518
Description
A small module with a pulse sensor and SpO2 level (oxygen saturation level). It is based on the MAX30102 chip and communicates via the I2C or UART interface (Gravity connector). The sensor consists of two LEDs, a photo detector, optimized optics and an analog signal processing circuit. MAX30102 provides a complete system solution to simplify the design process of mobile and wearable devices. The product wiki page offers complete documentation with examples of use.
Features
- Heart rate monitor and pulse oximeter
- Integrated protective glass
- Built-in photo detector and red, IR and green LEDs in one housing
- PWM control of individual LED channels
- 18-bit ADC converter:
- Sampling rate 10.24 MHz
- Output data transfer rate from 50 to 3200 sps
- FIFO (first input, first output) with a 32-element data buffer
- Integrated temperature sensor with a resolution of 0.0625°C
- I2C or UART interface
- I2C address: 0x57
- UART baudrate: 9600 bps
- Power supply 3.3 to 5 volts
- Current consumption: 15 mA
- Working temperature: -40°C to 85°C
Kit contains
- Gravity: MAX30102 Heart Rate and Oximeter Sensor
- Gravity cord
- Strap
