A LoRa communication node for mesh networks, enabling long-range data transmission up to 8-9 km in open terrain. Equipped with the XIAO nRF52840 Plus module, LoRa SX1262, and GPS L76K, it ensures efficient communication and precise positioning. Powered by a 5W solar panel and four 18650 batteries, it allows for long-term operation in the field without access to the grid. Seeed Studio 100023690

4 weeks
Awaiting delivery
Kamami is the official distributor of Seeed Studio modules and development kits. All products of this brand in our offer are original and come directly from the manufacturer.

Description

SenseCAP Solar Node P1-Pro is an advanced, autonomous communication node designed to operate within the MeshCore network, enabling secure text communication based on LoRa technology. The device comes preloaded with MeshCore Repeater firmware, allowing immediate deployment as a mesh network relay without the need for configuration. Powered by the XIAO nRF52840 Plus module and nRF52 architecture, the node offers very low power consumption while maintaining high processing performance. The built-in Wio-SX1262 LoRa module обеспечивает long-range wireless communication of up to 8–9 km in open areas.

The device is equipped with a 5W solar panel and four 18650 batteries with a capacity of 3350 mAh each, enabling long-term operation in outdoor environments without access to mains power. The power management system ensures continuous operation even under limited sunlight conditions, making it ideal for field deployments. The integrated L76K GPS module, supporting GPS, GLONASS, and Galileo systems, provides precise positioning and real-time location sharing.


SenseCAP Solar Node P1-Pro is designed for operation in harsh environmental conditions, making it well-suited for applications such as off-grid communication, emergency response, field monitoring, and IoT systems. The device supports integration with mobile applications and the MeshCore ecosystem, enabling easy network management and scalability. The Grove interface allows connection of additional modules and sensors.

Installation is quick and intuitive thanks to the plug-and-play design and included RF cable. A standard mounting kit allows easy installation in the desired location. Additional LED indicators provide information about operation status, charging, and network activity. SenseCAP Solar Node P1-Pro is a reliable solution for users seeking a scalable, energy-efficient, and robust communication infrastructure.

Features

  • Main controller: XIAO nRF52840 Plus (Nordic nRF52840, ARM Cortex-M4 32-bit, 64 MHz, 256 KB RAM, 1 MB Flash, 2 MB Flash)
  • LoRa module: Wio-SX1262 (Semtech SX1262, TXOP = 22 dBm @ 862–930 MHz)
  • GPS module: L76K (GPS/GLONASS/Galileo support)
  • Bluetooth: 5.0
  • Solar panel: 5 W
  • Power supply: Type-C 5V 1A and solar input 5V 1A
  • Battery: 4 × 18650 Li-ion (3350 mAh each)
  • Interfaces: Grove ×1 (IIC/GPIO/UART), USB-C (debugging)
  • Buttons: Power on/off, Reset, user button
  • LED indicators:
    • 2 × charging indicators
    • 1 × solar panel status
    • 1 × Mesh network status
    • 1 × user LED
  • LoRa antenna: rubber antenna, 868–915 MHz, 2 dBi gain
  • GNSS: GPS L1 (1575.42 MHz), GLONASS L1 (1602 MHz), BeiDou B1 (1561.098 MHz)
  • Communication range: up to 8–9 km (open area)
  • Certifications: FCC, CE
  • Discharge temperature range: -40 to 60°C
  • Charging temperature range: 0 to 50°C
  • Dimensions: 191.2 × 201.2 × 42.1 mm

Kit contains

  • SenseCAP Solar Node P1-Pro (with GPS and battery)
  • Mounting kit (universal joint, connector, bracket, clamp)
  • 2 dBi 868–915 MHz antenna
  • RF cable RP-SMA male to SMA female 300 mm
  • USB Type-C cable
