zł2,689.69 tax excl.
Module with 64 relays and 8 GPIO pins and 6 analog inputs. It communicates via the RS485, USB or Ethernet interface and supports the Modbus RTU/TCP protocol. Numato Lab NLRM1003-A
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Input/output module that supports communication within the Modbus RTU protocol via USB and RS485 and Modbus TCP via Ethernet. It is equipped with 64 relays and 8 additional inputs/outputs that support the functions of digital input, digital output and 6 analog inputs. RS485, USB and Ethernet interfaces make it easy for the user to connect the module to any devices with Windows, Linux, Mac or embedded computers such as RPi. Standard Modbus protocol support makes it easy to use with almost any automation software that supports Modbus RTU/TCP. The Prodigy ZRX is detected as a regular serial port and offers a clean interface to the device access. Flexible DIN rail mounting system allows easy installation and removal with screws. The module also supports such additional functions as a timer, Watchdog clock and a programmable switch-on state. Perfect for automation systems that require the control of multiple devices. Full documentation is available on the product page.
Features
- 32 SPST relays with a load capacity of up to 250V/5A
- 8 inputs/outputs supporting the functions of digital input, digital output 3.3V
- 6 analog inputs with a resolution of 12 bits
- USB CDC interface that works with Windows, Linux, Mac
- RS485 interface
- Ethernet interface
- Compatible with most of the automation software on the market that supports Modbus RTU/TCP
- Features such as time relay, watchdog timer for trouble-free operation, configurable on states
- 12 V power supply
- Dimensions: 340 x 160 mm
Kit contains
- Prodigy ZRX64
- USB - Ethernet cable
- Mounting brackets
- 12 V power supply
Data sheet
- Output current
- 5A
- Number of channels
- 64
- Executive element
- Przekaźnik
- Coil voltage
- 12 VDC
