Crowtail – Dual Coil Latching Relay Module 2.0 – 2-channel latching relay, 5 V, 3 A, low-power
search
  • Crowtail – Dual Coil Latching Relay Module 2.0 – 2-channel latching relay, 5 V, 3 A, low-power
  • Crowtail – Dual Coil Latching Relay Module 2.0 – 2-channel latching relay, 5 V, 3 A, low-power
  • Crowtail – Dual Coil Latching Relay Module 2.0 – 2-channel latching relay, 5 V, 3 A, low-power
ID: 1201696
zł16.79
Tax included

zł13.65 tax excl.

Crowtail – Dual Coil Latching Relay Module 2.0 is an energy-efficient dual-channel latching relay that retains its state after power loss. Intended for use in automation systems, remote control, and battery-powered projects.

Delivery date unknown
Out-of-Stock

Description

The Crowtail – Dual Coil Latching Relay Module 2.0 is a module with a dual-coil latching (bistable) relay that retains its last state (on/off) even after the power is disconnected. The state changes by applying a rising or falling pulse — it does not require continuous coil power. This makes the module ideal for use in low-power circuits, automation, remote control, and emergency power and communication systems. Its high switching capacity and compatibility with the Crowtail system allow easy integration with microcontrollers.

Properties

  • Relay type: latching, dual coil (2 Form C)
  • Operating voltage: 5 V
  • Maximum switching voltage: 35 V AC / 35 V DC
  • Maximum switching current: 3 A
  • Maximum set/reset voltage: 4.0 V DC
  • Set time: max. 4.5 ms
  • Reset time: max. 3.5 ms
  • Sensitivity: 150 mW
  • Switching capacity: 60 W / 125 VA
  • Epoxy-sealed housing – resistant to wave soldering and cleaning
  • Compatibility with 16-pin IC socket
  • Dimensions: 50.0 × 35.0 × 14.3 mm

Included

  • Crowtail – Dual Coil Latching Relay Module 2.0 module x1
  • Crowtail 4-pin cable x1
1201696

Data sheet

Output current
3A
Number of channels
2
Executive element
Impulse relay
Coil voltage
5 VDC
