Gravity: Analog Water Pressure Sensor - analog water pressure sensor
ID: 569876
5902186313408
zł88.89
Tax included
zł72.27 tax excl.
Water pressure sensor with 3-pin Gravity interface. It enables the measurement of liquid pressure in the range from 0 to 1.6 MPa. It is supplied with the voltage of 5 V and has a linear output voltage from 0.5 to 4.5 V. DFRobot SEN0257
Description
Water pressure sensor with 3-pin Gravity interface. It enables the measurement of liquid pressure in the range from 0 to 1.6 MPa. It is supplied with the voltage of 5 V and has a linear output voltage from 0.5 to 4.5 V. The sensor allows to detect the presence of a liquid and measure its pressure. It can be widely used in smart home control systems and in the IoT area. There is a user manual and examples of use on the Wiki page.
Features
- Liquid/gas
- Gravity-3Pin connector
- Pressure measurement range: 0 to 1.6 MPa
- Analog interface
- Output voltage: 0.5 to 4.5 V
- Measurement accuracy: 0.5% to 1% FS (0.5%, 0 to 55°C)
- Threaded: G1/4
- Adapter: G1/2 to G1/4
- Protection level: IP68
- Elapsed time: <2 ms
- Normal working pressure: ≤2MPa
- Failure pressure: ≥3.0MPa
- Number of cycles of use: 10,000,000 times
- Supply voltage: 5V
- Current consumption: 2.8 mA
- Working temperature: -20 to 85°C
Kit contains
- Water pressure sensor
- G1/2 to G1/4 adapter
569876
Data sheet
- Interface
- Sygnał analogowy
- Type of sensor
- inny
- Power supply voltage
- 5 V
- Sensor type
- Ciśnienia cieczy
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
