- Out-of-Stock
Panasonic NCR-18650B - Li-Ion 18650 3.7V 3400mAh battery
ID: 583264
Li-Ion battery type 18650 with a nominal voltage of 3.7 V and a capacity of 3400 mAh. Panasonic NCR-18650B
Description
The 18650 Li-Ion battery is a reliable power source that is used in a wide range of electronic devices, from flashlights to battery-powered devices. Thanks to its compact size and high capacity, this battery is an ideal solution for many applications, ensuring long-lasting operation without the need for frequent charging.
Attention!
The battery has no protection against overcharging and deep discharge. To charge the battery, use processor chargers with a charging cut-off at a voltage of 4.2 V.Features
- Technology: Li-Ion (lithium-ion)
- Type: 18650
- Nominal voltage: 3.7V
- Battery capacity: 3400 mAh
- Minimum capacity: 3250 mAh
- Charging current: 1.625 A.
- Maximum discharge current: 6.5 A
- Maximum charging voltage: 4.2V
- Maximum cut-off voltage: 2.5V
- Dimensions: 18.5 x 65.3 mm
- Weight: 47.5 g
583264
Data sheet
- Battery type
- 18650
Li-Ion - Output voltage
- 3.7V
- Battery capacity
- 3400 mAh
- Battery configuration
- 1S
- Number of cells
- 1
- Output/Connector
- none
- Length
- 65 mm
- Width
- 18,5 mm
- Thickness
- 18,5 mm
- Weight
- 47,5 g
Manufacturer Baltrade sp. z o.o. Geodetów 24 80-298 Gdańsk Poland baltrade@baltrade.pl
Responsible person Baltrade sp. z o.o. Geodetów 24 80-298 Gdańsk Poland baltrade@baltrade.pl
