zł22.45 tax excl.
Module with a touch keyboard (12 buttons) based on the ATtiny1616 microcontroller. The board is equipped with a Grove connector and communicates via the UART interface. Seeed Studio 101020636
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with a touch keyboard with 12 buttons in the form of a matrix of 3x4 buttons. It is based on an 8-bit ATtiny1616 microcontroller with a QTouch touch button controller. The microcontroller software can be modified by the user thanks to the derived UPDI interface. The board is equipped with a Grove connector, so it can be used with the Base Shield V2 and Arduino extension. The module communicates via the UART interface and is supplied with the voltage of 3.3 V or 5 V. Full documentation with examples of use is available on the product page.
Features
- ATtiny1616 microcontroller
- Number of buttons: 12
- Button type: touch
- UART interface
- Programming interface: UPDI
- Supply voltage: 3.3 V or 5 V
- Dimensions: 58 x 79 mm
Kit contains
- Grove 12-Channel Capacitive Touch Keypad
- Grove cable
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
