Module with IR thermal sensor Adafruit AMG8833
ID: 565765
5906623429608
zł228.87
Tax included
zł186.07 tax excl.
Module with a Panasonic sensor with an 8x8 IR thermal matrix (AMG8833 chip) with a built-in 3.3 V controller and a logic level translator. The I2C interface is used for communication. Adafruit 3538
Description
The Adafruit module contains a Panasonic sensor with an 8x8 IR thermal matrix (AMG8833 chip). It measures temperature in the range of 0 ~ 80 ° C with an accuracy of + - 2.5 ° C. It can detect a human from a distance of up to 7 meters. At a maximum frame rate of 10 Hz, it is ideal for creating your own human or mini infrared camera detector. The sensor, when connected to a microcontroller (or Raspberry Pi ), returns the array of 64 individual infrared temperature readings via the I2C interface.
The module has a built-in 3.3 V controller and a logic level translator. This allows you to use it with any 3V or 5V microcontroller or computer. The module has support in the form of Python libraries.
properties
- Measurement on an 8x8 matrix (AMG8833 from Panasonic)
- Temperature measurement range: 0 ~ 80 ° C
- Temperature measurement accuracy: +/- 2.5 ° C
- Built-in 3.3V controller and translator of logic levels
- Interface: I2C
- Dimensions: 25.8 x 25.5 x 6 mm
- Weight: 2.9 g
Included
- Module with IR thermal sensor Adafruit AMG8833
- Goldpin strip for men
