Wi-Fi 6 multimedia kit with ESP32-P4 and ESP32-C6, 32 MB PSRAM, 32 MB Flash, OV5647 camera, 8 Ω 2 W speaker - Waveshare 32021
ID: 1201093
5902186330382
zł126.21
Tax included
zł102.61 tax excl.
ESP32-P4-WIFI6-KIT-A is a comprehensive kit for implementing HMI applications, voice control and image processing, integrating a camera, microphone and speaker as well as Wi-Fi 6 and BLE wireless communication. Intended for advanced projects in the field of human–machine interaction and IoT solutions with hardware security.
Description
ESP32-P4-WIFI6-KIT-A is an advanced development kit based on the ESP32-P4-WIFI6-M board with soldered connectors, intended for advanced multimedia applications, HMI interfaces and solutions using voice control. The core of the system is the ESP32-P4 chip with a dual-core 400 MHz RISC-V processor and 32 MB PSRAM and 32 MB Flash memory. The ESP32-C6 chip serves as a Wi-Fi 6 (2.4 GHz) and Bluetooth 5/BLE communication module, using the SDIO interface.
The board offers an extensive set of interfaces: MIPI-CSI (with support for OV5647 cameras), MIPI-DSI, USB OTG 2.0 HS, I2S, SPI, I2C, UART, PWM, ADC, and a microSD card slot (SDIO 3.0). The integrated microphone and speaker connector (8 Ω, 2 W) allow the implementation of projects with voice interaction.
The kit includes a 5 MP OV5647 camera with manual focus adjustment and wiring enabling its quick connection. Compatibility of the 40-pin GPIO connector with Raspberry Pi Pico shields expands application possibilities. Hardware security mechanisms, including Secure Boot, Flash Encryption and TRNG, support the creation of applications requiring data protection.
Properties
- ESP32-P4 with RISC-V 400 MHz processor (dual-core)
- ESP32-C6 for Wi-Fi 6 and Bluetooth 5/BLE support (SDIO interface)
- 32 MB PSRAM and 32 MB Flash memory
- Interfaces: MIPI-CSI, MIPI-DSI, USB 2.0 OTG, SDIO 3.0, I2S, I2C, SPI, UART, PWM, ADC
- Multimedia processing support: JPEG Codec, H.264 encoder, Pixel Processing Accelerator
- Built-in microphone, connector for 8 Ω 2 W speaker (MX1.25)
- OV5647 5 MP camera with manual focus adjustment (MIPI-CSI interface)
- Compatibility with DSI displays (up to 10.1") – display not included in the kit
- 40-pin GPIO connector compatible with Raspberry Pi Pico
- Security mechanisms: Secure Boot, Flash Encryption, TRNG, access control
- USB Type-C connector for power and programming
- Support for AI voice interaction through external platforms (e.g. DeepSeek, Doubao)
- Dimensions: 71.05 x 21.00 mm
Included
- ESP32-P4-WIFI6-M with soldered connectors x1
- 8 Ω 2 W speaker x1
- Raspberry Pi Camera (B) 5 MP x1
- Pi5-Camera-Cable 200 mm x1
- FFC cable 15-PIN x1
- USB 4-PIN MX1.25 cable x1
1201093
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
