16 Channel Ethernet Relay Module - module with 16 12V relays and Ethernet communication
ID: 1180914
5906623411412
zł744.33
Tax included
zł605.15 tax excl.
Module with 16 12 V relays with a load of up to 7 A. The board communicates via the Ethernet interface. Numato Lab 16ETHRL001
Description
The module with 16 relays with a control voltage of 12 V and a load of up to 7 A and 8 GPIO pins that can work in the analog input mode. It enables the switching of high-power devices over Ethernet. For control, the user can use an easy-to-use interface launched in the browser or any terminal emulator supporting the TELNET protocol. Each module is shipped with a unique MAC address. These devices also support assigning and retrieving custom identification strings that can be used to distinguish individual devices when a large number of boards are connected to the same network. All outputs are available on screw terminals, which makes it easy to connect external devices. The module will be used in home automation projects, lighting systems and garden equipment. Full documentation is available on the product page.
Features
- 16 built-in 12 V relays
- Switching current 7 A
- Relay contacts available on screw terminals
- 8 TTL compatible GPIOs (3.3V)
- 8 analog input channels (multiplexed with GPIO)
- 10 bit resolution of the analog input
- Easy to use Relay / GPIO web interface
- Works with any TENET client
- Built-in unique MAC address and configurable identification string
- Dimensions: 205.105 x 115.570 x 20 mm
1180914
Data sheet
- Output current
- 7 A
- Number of channels
- 16
- Executive element
- Przekaźnik
- Coil voltage
- 12/24 VDC
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
