New products
New products
zł144.19 tax excl.
Module with 2 5 V relays with a maximum switching current of 2 A. It communicates via the USB interface and does not require an additional power supply. Numato Lab USBPOWRL001
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with 2 relays and 4 IO pins (with analog input function) supporting communication via USB. It can control devices with a current of up to 2 A. The USB interface allows the user to easily connect the module to any devices with Windows, Linux, Mac or embedded computers such as RPi. It comes with built-in software that supports simple commands to control the relays and read their status. The board appears as a serial port when connected to a computer and can be operated by serial terminal applications such as HyperTerminal or Putty. Due to the fact that it uses 5V relays, it does not require any additional power supply (only via the USB port). Perfect for automation systems that require the control of multiple devices. Full documentation is available on the product page.
Features
- 2 DPDT 5V relays
- Switching current 2 A
- 4 IO TTL 3.3V
- 4 analog inputs (multiplexed with IO)
- Resolution of analog inputs 10 bits
- USB interface with CDC support
- Relay contacts available on screw terminals
- It can be controlled by standard serial console applications
- USB powered
- Dimensions: 60.2 x 45.5 mm
