PIPPY-ACCE - a set of accessories for building a walking robot with Raspberry Pi 4
ID: 584590
5906623439577
zł612.37
Tax included
zł497.86 tax excl.
A set of accessories for building a four-legged walking robot based on the popular Raspberry Pi 4 minicomputer. Waveshare PIPPY-ACCE
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Opis
A set of accessories for building a four-legged walking robot based on the popular Raspberry Pi 4 model B minicomputer. The set consists of a structure based on servos, a 5MP camera with an OV5647 sensor and the necessary accessories.
Attention!
The kit does not include the Raspberry Pi 4 model B kit and the micro SD card. They must be purchased separately. Only 18650 batteries shorter than 67 mm are compatible with the set.
The robot is based on a four-leg design with durable MG90S servos with a metal gear. The housing is made of aluminum. The robot expansion board houses the servo controller, OLED display, 9-axis IMU sensor and protection circuit, and a basket for 2 18650 battery cells.
The set can be used to build a robot controlled by a computer or a mobile device. It can also be an excellent driving base for creating an autonomous structure based on motion and object detection. The set is compatible with OpenCV libraries, which allows for advanced image processing.
Full documentation is available on the product Wiki page.
Features
- Designed for Raspberry Pi 4 model B
- Raspberry Pi OS (Raspbian) operating system
- Programming language: Python
- 5MP HD camera, 160° FOV wide angle
- 0.91 "128 x 32 pixel OLED display
- 2.4 GHz/5 GHz WiFi module, Bluetooth 5.0
- Control: web browser
- Overcharge/discharge protection, overcurrent protection, short circuit protection, reverse polarity protection
- Power supply: 8.4 V, 2 x 18650 battery
- Servo with MG90S metal gear
- Aluminum alloy housing
Kit contains
- Metal PIPPY box
- PIPPY base plate
- RPi (G) Camera
- Acrylic camera pad
- Ultrasonic module
- 4-pin connection cable
- Mini cross wrench sleeve
- MicroSD card reader
- 8 x Servo with metal gear
- 8.4 V battery charger + EU adapter
- 2 x Screwdriver
- Bolts and spacers
