PiRacer AI Kit accessory set for building robot with Raspberry Pi 4 - Waveshare 17674
ID: 584579
5906623439560
zł672.26
Tax included
zł546.55 tax excl.
A set of accessories for building an autonomous racing robot based on the popular Raspberry Pi 4 model B development kit. Waveshare PiRacer AI Kit Acce
Description
A set of accessories for building an autonomous racing robot based on the popular Raspberry Pi 4 model B development kit. The set consists of a racing chassis, an 5MP camera with a OV5647 sensor and the necessary accessories.
Attention!
The kit does not include the Raspberry Pi 4 model B kit and the micro SD card. They must be purchased separately. Only 18650 batteries shorter than 67 mm are compatible with the set.
The chassis is a structure based on the Ackerman principle with a drive motor with a metal gearbox with a speed of 740 rpm and a front steering axle with an MG996R servo. The chassis skeleton is made of aluminum. The robot expansion board houses the motor controller, OLED display and protection circuit, and a basket for 3 18650 battery cells.
The set can be used to build a racing vehicle controlled by the included gamepad, computer or mobile device. It can also be an excellent driving base for creating an autonomous vehicle. The set has a very rich support in the form of tools such as TensorFlow, OpenCV, Keras as well as DonkeyCar, a platform that uses neural networks and deep learning mechanisms, which with the support of Keras, TensorFlow and OpenCV allows you to build your own autonomous vehicle.
Full documentation and assembly instructions are available on the product Wiki page.
Features
- Compatible with Raspberry Pi 4 model B
- Raspberry Pi OS (Raspbian) operating system
- Programming language: Python
- 5MP HD camera, 160 ° FOV wide angle
- 0.91 "128 x 32 pixel OLED display
- 2.4 GHz/5 GHz WiFi, Bluetooth 5.0
- Controls: gamepad, web browser
- Overcharge / discharge protection, overcurrent protection, short circuit protection, reverse polarity protection
- Chassis type: steered according to the Ackerman principle, rear-wheel drive with double geared motor
- Power supply: 12.6 V, 3 x 18650 battery
- 37-520 DC motor, 1:10 gear, rotation speed 740 rpm
- MG996R servo, 9 kg / cm
- Aluminum alloy housing
- Front bumper
- Software libraries: DonkeyCar
Kit contains
- PiRacer undercarriage components
- 2 x EVA felt pad
- 3D printed engine cover
- PiRacer expansion board
- RPi camera
- Acrylic tile
- Servo mounting
- 2 x Gear motor
- 4 x Tires
- 2 x Connector
- Servo MG996R
- Servo adapter MG996R
- 2 x switches
- 4 x Ball bearing
- 4 x M3 plastic ball joint
- 2 x M3
- 12.6 V charger + EU adapter
- Wireless gamepad
- 6-pin cable
- 2 x Wrench
- 2 x Screwdriver
- Mini cross wrench sleeve
- MicroSD card reader
- Screw package
- Test route
