New products
New products
zł158.56 tax excl.
Converter that provides easy communication between the RS485 and RJ45 Ethernet interface. It supports the Modbus RTU and Modbus TCP protocols. USR-N510
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Converter that provides easy communication between the RS485 and RJ45 Ethernet interface. It supports popular network protocols, including IP, TCP, UDP, DHCP, DNS, HTTP, ARP, ICMP, Websocket and HTTP client, and supports Modbus RTU and Modbus TCP protocols. It is configured using the built-in website, commands issued via the serial port or using dedicated software. The converter is equipped with an RJ45 connector and screw connectors for connecting the RS486 interface and power supply. It will be used in industrial applications.
Features
- Microcontroller: ST with ARM Cortex-M4, 120 MHz
- Ethernet 8-pin RJ45 connector
- LED indicator: 10/100Mbps, MDI/MDIX, auto switch between cross and direct connection
- 2KV electromagnetic isolation
- Network Protocol: IP, TCP, UDP, DHCP, DNS, HTTP, ARP, ICMP, Websocket, HTTP client
- Interface: RS485
- Transmission speed: 600 bps to 230.4 Kbps
- Flow control
- RS485 resistor: 2.2 kΩ
- It supports the Modbus RTU and Modbus TCP protocols
- Virtual Serial (USR-VCOM), Windows 2000 or later (32-bit/64-bit)
- Embedded web page, PC configuration software
- Input voltage: DC 5 to 36V
- Working current: 53mA
- Operating temperature: -40 to 85°C
- Dimensions: 88 x 81 x 24mm
