Dual-channel industrial RS485-to-Ethernet PoE converter (B) - Waveshare 24963
ID: 1186169
5906623465910
zł157.00
Tax included
zł127.64 tax excl.
2-channel RS485 to Ethernet converter designed for industrial environment. It connects serial server, Modbus gateway, MQTT gateway, RS485 to JSON and network switch. It has two RS485 ports and two Ethernet ports with PoE function. Waveshare 2-CH RS485 TO POE ETH (B)
Description
2-channel RS485 to Ethernet converter designed for industrial environment. Both channels of the converter can work simultaneously without interfering with each other. It combines many functions in one, including serial server, Modbus gateway, MQTT gateway, RS485 to JSON and network switch. It has two RS485 ports and two Ethernet ports with PoE function, and uses a DC port and a screw terminal as a power input. The applied housing with a rail mounting bracket is easy to install in industrial control cabinets. The converter can be used for applications such as data acquisition, IoT gateway, IoT security and smart instrument monitoring. Full documentation is available on the product page.
Features
- 2 x RJ45 Ethernet connector
- Communication speed: 10/100Mbps
- Interface protection: 2 kV electromagnetic isolation
- Power and signal isolation
- 2 x RS485 port on screw connector
- Data bits: 5 to 9 bits
- Parity bit: none, odd, even, sign, space
- ETHERNET protocol, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS
- Support for MQTT, Modbus, JSON
- Configuration: web browser, library of device management functions
- Direct TCP/IP, VCOM communication
- Working mode: TCP server, TCP client (coexisting with TCP server), UDP, UDP multicast
- Power supply: 6 to 40 V, PoE port
- Operating temperature: -40 to 85°C
- Storage temperature: -45 to 125°C
- Dimensions: 78 x 72.5 x 24.2mm
