A module with an acceleration and rotational speed sensor based on the MPU-6050 system. It communicates via the I2C interface. DFRobot SEN0142

4 weeks
Awaiting delivery
Kamami is the official distributor of DFRobot modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.

Description

6 DoF module with a 3-axis accelerometer and a 3-axis gyroscope based on the MPU-6050 system. It allows you to measure acceleration relative to the Earth with a programmable range of ± 2g, ± 4g, ± 8g or ± 16g and rotational speed with a range of ± 250, ± 500, ± 1000 or ± 2000 °/s, which allows you to determine the orientation in space. It will work, among others in projects of mobile robots or flying objects (UAV). The module is compatible with 3.3 V and 5 V controllers, and communication is via the I2C interface. Full documentation with examples of use is available on the product wiki page.

Features

  • Gyroscope:
    • Programmable range ± 250, ± 500, ± 1000 and ± 2000 ° / s
    • External synchronization signal connected to the FSYNC pin
    • Integrated 16-bit ADC converters
    • Improved sensitivity temperature bias and stability reduces the need for calibration
    • Improved low frequency noise performance
    • Digitally programmable low-pass filter
    • Gyro working current: 3.6mA
    • Standby current: 5µA
    • Factory calibrated sensitivity scale factor
  • Accelerometer:
    • Triaxial accelerometer with digital output with programmable ranges of ± 2g, ± 4g, ± 8g and ± 16g
    • Integrated 16-bit ADC converters
    • Normal operating current of the accelerometer: 500 µA
    • Current in Low Power Mode: 10 µA at 1.25 Hz, 20 µA at 5 Hz, 60 µA at 20 Hz, 110 µA at 40 Hz
    • Orientation detection and signaling
    • User programmable interrupts
    • Interruption of the free fall
    • User self-test
  • I2C interface
  • Supply voltage: 3.3 V to 5 V
  • Dimensions: 21 x 14 mm

Kit contains

  • Fermion module: MPU-6050 6 DOF Sensor
  • 5-pin goldpin male connector
580957

Data sheet

Interface
I2C
Type of sensor
MPU6050
Module type
6DoF
Power supply voltage
3 - 5 V
Sensor type
Akcelerometr i żyroskop
