OP5000-3 - 5000X tip for SigOFIT Micsig 350MHz probe
ID: 1197265
zł3,874.19
Tax included
zł3,149.75 tax excl.
A probe tip with attenuation factor of 5000X. Dedicated to Micsig probes from the SigOFIT series operating in the frequency band of 100MHz, 200MHz and 350MHz. Micsig OP5000-3
Description
The 5000X attenuation probe tip is designed to extend the measurement range of Micsig high-frequency probes. It enables operation at high voltages while ensuring safety and measurement accuracy. Thanks to its low input impedance, it minimizes interference with the tested signal. Fully compatible with OIP350 probes, this tip is suitable for signal analysis up to 100MHz, 200MHz, and 350MHz, both in laboratories and in the field. Its compact design facilitates access to hard-to-reach measurement points.
Features
- Attenuation ratio: 5000:1 @0dB ±6250V, 500:1 @20dB ±625V
- Maximum operating voltage: ± 8000Vpp
- Input impedance: 40.82MΩ || 2.4pF
- Compatible with OIP350 probes
- Adapter type: LCX
1197265
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
