STEMMA QT AHT20 Temperature & Humidity Sensor - module with a temperature and humidity sensor
ID: 587244
5906623430215
€6.39
Tax included
€5.20 tax excl.
A module with a temperature and humidity sensor based on the AHT20 system. Equipped with a STEMMA QT connector, it communicates via the I2C interface. Adafruit 4566
Description
A module with a temperature and humidity sensor based on the AHT20 system. It has an accuracy of ± 2% when measuring relative humidity from 20 to 80% and an accuracy of ± 0.3°C when measuring temperatures from 20 to 60°C. The module is compatible with 3.3 V and 5 V controllers, and communication is via the I2C interface (STEMMA QT connector). Full documentation is available on the product page.
Features
- Temperature measurement range: -40 to 85°C (accuracy: ± 1°C)
- Humidity measuring range: 0 to 100% RH (accuracy: ± 3% RH)
- I2C interface (address 0x38)
- Supply voltage: 3.3 V to 5 V
Kit contains
- STEMMA QT AHT20 Temperature & Humidity Sensor
- 6-pin goldpin male connector
587244
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
