USB camera module 2 MP OV2710 (A) - Waveshare 14121
ID: 1180724
zł175.29
Tax included
zł142.51 tax excl.
Camera module with USB interface. Equipped with a CMOS OV2710 sensor with a resolution of 2 MP and a lens with a viewing angle of 145°. Waveshare OV2710 2MP USB Camera (A)
Description
Camera with USB interface, equipped with CMOS sensor OV2710 1/2.7” with a resolution of 2 MPx. It has a built-in IR filter and is equipped with lenses with a field of view of 145°. The camera can take pictures with a resolution of 1920Hx1080V and record videos in 30fps @ 1920x1080. It is powered from the USB port. The module works with native drivers (compatible with UVC) built into Windows, Linux, making the installation of the camera easy and intuitive. It will be used in face recognition applications. Full documentation and examples of use are available on the product page.
Features
- 1/2.7” CMOS OV2710 sensor
- Resolution: 2MP 1920Hx1080V
- Data format: MJPG / YUY2
- Frame rate: MJPG 30fps @ 1920 x 1080; YUY2 30fps @ 640 x 480
- Field of View (FOV): 145 °
- Focal length: 2.9 mm
- Aperture: 2.8
- Integrated IR filter
- Automatic calibration of saturation, contrast, sharpness, white balance, exposure
- System Compatibility: Windows, Linux with UVC
- USB 5V power supply
- Working temperature: 0 to 50°C
- Dimensions: 38 x 38 mm
Kit contains
- OV2710 2MP USB Camera (A)
- 4-pin USB cable
1180724
Data sheet
- Resolution
- 2Mpx
- Interface
- USB
- Sensor
- OV2710
- IR filter
- Yes
- Lens assembly
- none
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
