ArduCAM 8MP 1080P Auto Focus USB Spy Camera - 8MP USB camera with IMX179 sensor and microphone + case with tripod
ID: 586965
5906623404230
Camera with a resolution of 8 MPx with a USB interface. Equipped with CMOS IMX179 sensor with 75° lens, microphone, housing and tripod. ArduCAM UB019701
Description
Camera with USB interface equipped with CMOS IMX179 1/3.2” sensor with 8 MPx resolution. It has an integrated IR filter and a lens with a field of view of 75°. The camera can take pictures with a resolution of 3264H x 2448V and record videos at 15fps @ 3264x2448. There is a microphone on the board that allows you to add an audio track to video files. It is powered from the USB port. The module works with native drivers (compatible with UVC) built into Windows, Linux, Mac and Android, making the installation of the camera easy and intuitive. The plate is enclosed in a protective casing placed on a tripod. The camera will be used for monitoring 3D printing and videoconferences.
Features
- Sensor: 1/3.2” CMOS IMX179
- Resolution: 8MP 3264H x 2448V
- Data format: MJPG/YUY2
- Frame rate: MJPG 15fps @ 3264 x 2448, 30fps @ 1080P; YUY2 30fps @ 640x 480
- Field of View (FOV): D = 74.6 °, H = 64.5 °, V = 46.6 °
- Lens mount: M6.5
- Integrated IR filter, only visible light
- Automatic calibration of saturation, contrast, sharpness, white balance, exposure
- System Compatibility: Windows, Linux, Mac and Android with UVC
- Built-in microphone
- Metal housing and tripod
- USB 5V power supply
- Working current: 350 mA
- Working temperature: -20 to 75°C
- Dimensions: 39 x 42 mm
- USB cable length: 1 m
Kit contains
- ArduCAM 8MP 1080P Auto Focus USB Spy Camera module with a tripod
- USB 2.0 cable 1 m
586965
Data sheet
- Resolution
- 8MPx
- Interface
- USB 2.0
- Sensor
- Sony IMX179
- IR filter
- Yes
- Lens assembly
- M6.5
