Espressif ESP32-C3FH4 WiFi module board with RISC-V core. It offers 4 MB Flash memory and 400 kB SRAM and an RGB LED. It has a built-in ceramic WiFi/BLE antenna. Waveshare ESP32-C3-Zero

24h
Available
Available quantity: 20
ESP32 - board with the ESP32 WiFi module:
C3-Zero (without connectors)
C3--Zero-M (with connectors) S3-Zero (without connectors) S3-Zero-M (with connectors)
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

Espressif ESP32-C3FH4 WiFi module board with RISC-V core. It has 4 MB Flash memory, 400 KB SRAM memory and an integrated 2.4 GHz WiFi and BLE transceiver. The board has a WS2812 RGB diode and a 3.3 V stabilizer with a current capacity of up to 500 mA. On 15 GPIO pins, the user has analog inputs, PWM, I2C, UART, SPI and I2S interface at their disposal. The integrated chip antenna ensures good quality of WiFi and BLE communication with a satisfactory range.


1. USB typu C connector            5. 3,3 V LDO
2. BOOT button 6. ESP32-C3FN4
3. RESET button 7. Ceramic antenna
4. LED RGB WS2812

The module offers great potential in the field of IoT systems and can be used both to control LEDs and to transmit data to a specific platform. It can also be programmed using Arduino IDE, ESP-IDF or MicroPython. Full documentation is available on the product page.

Features

  • 32-bit single-core RISC-V processor
  • 4 MB SPI Flash memory
  • 400 kB SRAM
  • 384 kB ROM
  • Wi-Fi 2.4 GHz, BLE
  • SMD antenna
  • LDO stabilizer 3.3V 500mA
  • Optimized power system ensuring low energy consumption
  • Power supply: USB Type-C
  • RGB WS2812 LED
  • 15 GPIO pins: ADC 12-bit, PWM, I2C, 2 x UART, 3 x SPI, I2S
  • Dimensions: 23.5 x 18 mm
