ESP32-S3-Zero-M board with ESP32-S3 Wi-Fi module and connectors - Waveshare 25517
search
  • ESP32-S3-Zero-M board with ESP32-S3 Wi-Fi module and connectors - Waveshare 25517
  • ESP32-S3-Zero-M board with ESP32-S3 Wi-Fi module and connectors - Waveshare 25517
  • ESP32-S3-Zero-M board with ESP32-S3 Wi-Fi module and connectors - Waveshare 25517
  • ESP32-S3-Zero-M board with ESP32-S3 Wi-Fi module and connectors - Waveshare 25517
ID: 1187950
5906623423965
zł27.69
Tax included

zł22.51 tax excl.

Espressif ESP32-S3 WiFi module board with 32-bit dual-core Xtensa 32-bit LX7 processor. It offers 4 MB Flash memory and 512 kB SRAM and an RGB LED. It has a built-in ceramic WiFi/BLE antenna. Waveshare ESP32-S3-Zero-M

24h
Available
Available quantity: 89
ESP32 - board with the ESP32 WiFi module:
C3-Zero (without connectors) C3--Zero-M (with connectors) S3-Zero (without connectors)
S3-Zero-M (with connectors)
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

A board with an Espressif ESP32-S3 WiFi module equipped with 4 MB of Flash memory, 2 MB of PSRAM memory and an integrated WiFi 802.11 b/g/n and Bluetooth transceiver supporting the BLE 5 standard. The board has a WS2812 RGB diode and a 3.3 V stabilizer with current efficiency. up to 800 mA. On 24 GPIO pins, the user has analog inputs, PWM, I2C, UART, SPI and I2S interface at their disposal. The integrated chip antenna ensures good quality of WiFi and BLE communication with a satisfactory range.


1. ESP32-S3FFH4R2            5. Ceramic antenna 2,4GHz
2. USB typu C 6. BOOT Button
3. LDO 3,3 V 7. RESET Button
4. LED RGB WS2812 8. ESP32-S3 pins

The module offers great potential in the field of IoT systems and can be used both to control LEDs and to transmit data to a specific platform. It can also be programmed using Arduino IDE, ESP-IDF or MicroPython. Full documentation is available on the product page.

Features

  • 32-bit Xtensa 32-bit LX7 240 MHz dual-core processor
  • Integrated 512 kB SRAM, 384 kB ROM, 4 MB Flash, 2 MB PSRAM
  • Wi-Fi 2.4 GHz 802.11b/g/n
  • Bluetooth LE 5
  • Ceramic antenna
  • LDO stabilizer 3.3V 0.8A
  • Optimized power system ensuring low energy consumption
  • Power supply: USB Type-C
  • 24 GPIO pins including ADC, UART, SPI, I2C, PWM
  • Dimensions: 23.5 x 18 mm
