ESP32-C6 Module with 1.54″ LCD 240 × 240px, EN Version - Waveshare 34660
ID: 1207046
zł68.19
Tax included
zł55.44 tax excl.
ESP32-C6 development module with a 1.54-inch 240 × 240px IPS LCD and support for Wi-Fi 6, Bluetooth 5 LE and IEEE 802.15.4. Features a QMI8658 6-axis IMU, dual microphones, speaker, TF card slot, USB-C and 3.7V battery interface; non-touch EN variant. Waveshare ESP32-C6-LCD-1.54-EN
Description
The device Waveshare ESP32-C6-LCD-1.54-EN uses the ESP32-C6 microcontroller with a 32-bit single-core RISC-V processor running at up to 160MHz. The controller provides 512KB SRAM, 320KB ROM and 16MB Flash memory. Wireless connectivity includes 2.4GHz Wi-Fi 6, Bluetooth 5 LE and IEEE 802.15.4, supporting projects based on protocols including Zigbee 3.0 and Thread.
The onboard 1.54-inch IPS LCD provides a 240 × 240px resolution and supports 262K colors. The display uses the ST7789 controller and communicates through a 4-wire SPI interface. Waveshare 34660 does not include a touch panel. The display can be used for status screens, HMI interfaces, IoT devices and compact graphical applications.
The module integrates a QMI8658 6-axis IMU with a 3-axis accelerometer and 3-axis gyroscope, an ES7210 IC for dual-microphone capture, ES8311 audio codec, NS4150B amplifier and speaker. The hardware supports applications involving audio capture and playback, voice functions and motion or orientation detection. Additional hardware includes a TF / microSD card slot, PLUS, PWR and BOOT buttons, a USB Type-C port and I2C and UART expansion pads.
The MX1.25 2PIN connector supports a 3.7V lithium battery together with charge and discharge management. The -EN designation identifies Waveshare SKU 34660; the available manufacturer documentation does not specify separate hardware parameters compared with the ESP32-C6-LCD-1.54 variant.
Features
- Manufacturer: Waveshare
- Product number: 34660
- Model: ESP32-C6-LCD-1.54-EN
- Variant: EN
- Touch panel: none
- Microcontroller: ESP32-C6
- Processor: 32-bit single-core RISC-V
- Clock frequency: up to 160MHz
- SRAM: 512KB
- ROM: 320KB
- Flash: 16MB
- Wi-Fi: 2.4GHz Wi-Fi 6
- Bluetooth: Bluetooth 5 LE
- IEEE 802.15.4: supported
- Supported protocols: Zigbee 3.0, Thread
- Antenna: onboard
- Display: 1.54-inch IPS LCD
- Resolution: 240 × 240px
- Display colors: 262K
- LCD controller: ST7789
- LCD interface: 4-wire SPI
- Active display area: 27.72 × 27.72mm
- IMU: QMI8658, 6-axis
- IMU sensors: 3-axis accelerometer and 3-axis gyroscope
- Microphones: 2
- Audio IC: ES7210
- Audio codec: ES8311
- Audio amplifier: NS4150B
- Speaker: onboard
- Memory card slot: TF / microSD
- USB: USB Type-C
- Expansion interfaces: I2C, UART, USB
- Buttons: PLUS, PWR, BOOT
- Battery connector: MX1.25 2PIN
- Supported battery voltage: 3.7V
- Battery charging and discharging support
- Development environments: Arduino IDE, ESP-IDF
