ESP32-S3 development board with 2″ display 240×320 - Waveshare 30306
ID: 1197675
5902186303683
zł64.05
Tax included
zł52.07 tax excl.
ESP32-S3-LCD-2 is a versatile development board with a 2" display and Wi-Fi/Bluetooth connectivity, which, thanks to its compact size and built-in motion sensor, is suitable for portable graphic applications and IoT projects. Although the OV5640 camera module is not included in the set, the board remains compatible with such solutions, allowing future expansion with image and video capture functions.
Description
ESP32-S3-LCD-2 is a compact development board with the ESP32-S3R8 microcontroller, featuring a 2-inch color IPS display with a resolution of 240×320 pixels. The display is driven by the ST7789T3 controller communicating via the SPI interface, which helps conserve GPIO lines. The module integrates a dual-core Xtensa LX7 processor running at up to 240 MHz, 2.4 GHz Wi-Fi connectivity, and Bluetooth 5 LE with a built-in antenna. The board also includes a 6-axis QMI8658 sensor (accelerometer + gyroscope), a TF card slot, a connector for charging a 3.7 V lithium battery, and a USB Type-C port for power and programming. Despite having a camera connector, the standard version does not include the OV5640 module. This board is ideal for AIoT projects, data loggers, and portable graphic applications.
Features
- Processor: Xtensa 32-bit LX7 dual-core, up to 240 MHz
- Connectivity: Wi-Fi 2.4 GHz (802.11 b/g/n) and Bluetooth 5 LE
- Memory: 512 KB SRAM, 384 KB ROM, 8 MB PSRAM, 16 MB Flash
- Display: 2" IPS, 240×320 resolution, 262K colors, ST7789T3 controller, SPI interface
- Sensor: QMI8658 – 3-axis accelerometer and gyroscope
- TF card slot for data storage
- USB Type-C port for power, programming, and debugging
- MX1.25 connector for 3.7 V lithium battery
- 22 GPIO pins for flexible function assignment
- Camera connector compatible with OV2640 and OV5640 (camera module not included)
- Supports ESP-IDF and Arduino IDE
