ESP32-S3-LCD-1.3-B is a compact development module with a 1.3" color IPS screen, Wi-Fi and Bluetooth communication, motion sensors, and a plastic enclosure, designed for graphic projects, interactive mobile applications, wearable electronics prototypes, and data acquisition systems. With SPI support and hardware display rotation, it enables flexible implementation in projects requiring color graphics display.

24h
Available
Available quantity: 3
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

Module based on the ESP32-S3R8 microcontroller with a dual-core Xtensa LX7 processor clocked up to 240 MHz. Equipped with a 1.3-inch color IPS display with a resolution of 240×240 pixels, controlled by the ST7789V2 driver via SPI interface. The device integrates 8 MB of PSRAM, 16 MB of Flash memory, and 2.4 GHz Wi-Fi and Bluetooth 5 LE communication modules.

It includes a QMI8658 IMU sensor (3-axis accelerometer and 3-axis gyroscope), a TF card slot, a 3.7 V lithium battery charging management system, and a 13-pin GPIO connector (2.54 mm). Its compact design enclosed in a lightweight plastic case allows for convenient integration with end-user devices.

It supports 90° hardware display rotation, allowing flexible use of the screen in different orientations.

Features

  • ESP32-S3R8 with dual-core Xtensa 32-bit LX7 processor up to 240 MHz
  • Support for 2.4 GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 LE
  • 16 MB Flash, 8 MB PSRAM, 512 kB SRAM, 384 kB ROM
  • 1.3" IPS display, 240×240 px, 262K colors
  • ST7789V2 controller, SPI interface, 90° hardware rotation support
  • QMI8658 IMU sensor (3-axis accelerometer and 3-axis gyroscope)
  • TF card slot, charge indicator, MX1.25 battery connector
  • Battery charging management with PL4054, voltage regulator ME6217C33M5G
  • 13PIN GPIO connector (2.54 mm) for connecting peripherals
  • Plastic enclosure
