zł472.48 tax excl.
LoRaWAN SX1303 module is equipped with a Mini-PCIe connector. It uses the SPI or I2C interface for communication. Waveshare SX1303 868M LoRaWAN Gateway (B)
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The module with LoRa communication is equipped with a Mini-PCIe connector. It offers long-range transmission in the 868 MHz frequency band with LoRa/(G)FSK modulation, with concurrent communication and FEC (Forward Error Correction) algorithm, which provides higher anti-interference efficiency and translates into longer communication distance. It offers high reception sensitivity and uses the SPI or I2C interface for communication. The SX1303 supports Fine Timestamp and network positioning based on time difference of arrival (TDOA). It can be used as a control element for valves, air conditioning or measuring devices in industrial applications and the IoT area. Full documentation with the C library is available on the product page.
Features
- LoRa SX1303 module
- Frequency band: EU868, IN865, RU864 (863-870MHz)
- Modulation: LoRa/(G)FSK
- Transmit power:> 26 dBm @ 5V
- Receiving sensitivity: -141dBm @ 125KHz/SF12, -121dBm @ 125KHz/SF5
- Interface: SPI, I2C
- Connector: Mini-PCIe 52 pin
- Power supply: 5V
- Current Consumption: 427mA @ 5V (transmit), 40mA @ 5V (receive), 8mA @ 5V (sleep mode)
- Dimensions: 50.95 x 30 mm
Kit contains
- SX1303 868M LoRaWAN Gateway Module (B)
- IPEX1 cable to SMA
- 868M 5dBi antenna
