ID: 1188720
5906623400034
zł1,114.56
Tax included

zł906.15 tax excl.

Micsig MDP series differential probe based on advanced SigOFIT technology. It offers a frequency band of 100 MHz and the ability to measure voltage up to 700 V. It uses the popular BNC connector and is powered by a USB Type-C connector. Micsig MDP700

24h
Available
Available quantity: 4
Kamami is the official distributor of Micsig oscilloscopes and accessories. All products of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The differential probe based on Micsig's advanced SigOFIT technology is a modern tool that is characterized by a very low noise level, excellent amplitude and frequency characteristics at high voltage and an advanced ability to reject common-mode signals. Thanks to these features, users can easily test high-frequency and voltage signals. The probe has a bandwidth limit of 5 MHz, which effectively eliminates high-frequency noise when measuring transistor switching frequencies in most switching power supplies. Additionally, the zero point calibration function allows you to zero the probe instantly. The probe also offers dual-range capability, improving signal-to-noise ratio and adapting to a variety of test requirements. The standard BNC connector allows operation with any oscilloscope, and the power supply from the USB port eliminates the need for additional power sources.

Additional features, such as an overvoltage alarm with a flashing LED and an out-of-range alarm, allow the user to quickly respond to possible problems. The MDP probe also stands out for its compact and aesthetic design, much smaller than traditional differential probes. Moreover, it is characterized by excellent bandwidth uniformity, with amplitude fluctuations below 0.5 dB in the half-band range, even in the case of high frequencies, which guarantees high measurement precision. High input impedance and low capacitance minimize the loading effect, which greatly improves the accuracy of differential signal measurement.

The probe can be widely used for AC voltage measurements, high voltage insulation measurements, and the design of switching power supplies and power converters. It is a versatile and flexible tool useful both in an electronics workshop and in an industrial environment.

Features

  • Frequency band: 100MHz
  • Rise time: ≤ 3.5 ns
  • Attenuation Ratio: 20X, 200X
  • Accuracy: ±2%
  • Max. differential voltage (DC+AC PK):
    • 20X: 70V
    • 200X: 700V
  • Max. common mode voltage: CAT I 600V, CAT II 450V
  • Noise:
    • Full Bandwidth:
      • 20X: ≤ 22mVrms
      • 200X: ≤ 80mVrms
    • 5MHz Bandwidth Limit:
      • 20X: ≤ 8mVrms
      • 200X: ≤ 70mVrms
  • CMRR:
    • DC: > -80dB
    • 100 kHz: > -60dB
    • 10 MHz: > -30dB
    • 100 MHz: > -26dB
  • Input impedance:
    • Differential mode: 16 MΩ, 1.5 pF
    • Common mode: 8 MΩ, 3 pF
  • Delay:
    • 20X: 11.99 ns
    • 200X: 12.27 ns
  • Output voltage: ≤3V
  • Bandwidth limit: 5MHz
  • Quick zero point calibration function
  • Two working ranges
  • Signaling of exceeding the permissible voltage: LED and buzzer
  • BNC connector
  • Power supply: USB Type-C
  • Operating temperature range: 0℃ to 40℃
  • Cable length: 8 cm (input), 120 cm (output)
  • Control module dimensions: 91 x 33 x 15 mm
  • Signal module dimensions: 100 x 36 x 20 mm

Kit contains

  • Differential probe
  • USB cable
  • 2 x alligator clips
  • 2 x measuring tip
