HLK-PM01 - miniature modular 5V 3W power supply
ID: 584421
5906623461509
zł14.90
Tax included
zł12.11 tax excl.
Modular power supply with a power of 3 W, input voltage from 100 to 240 V and output voltage of 5 V. Designed for mounting on a PCB. Hi-Link HLK-PM01
Description
Modular power supply with a power of 3 W, designed for mounting on a PCB. It can accept an input voltage of 100 to 240 V AC and has an output voltage of 5 V DC. It is characterized by a maximum output current of up to 0,6 A, low ripple, as well as overload and short-circuit protection. Perfect as a power supply in small projects powered by alternating voltage, e.g. from the IoT area.
Features
- Input voltage: 100 to 240 V AC
- Output voltage: 5 V DC
- Max. input current: 0.2 A
- Max. output current: 0,6 A
- Efficiency at 220 V AC: 70%
- Overcurrent, short-circuit and thermal protection
- Working temperature: -20°C to 60°C
- Permissible ambient humidity: 5 to 95%
- Dimensions: 34 x 20.2 x 15 mm
584421
Data sheet
- Output voltage
- 5th
- Output current
- 0.6A
- Converter type
- Step-down
- Supply voltage min
- 100 V AC
- Supply voltages max
- 240 V AC
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
